ThinkPHP8实战：构建高性能API网关系统 | 微服务架构设计

一、系统架构设计

本教程将实现一个完整的API网关系统，主要解决以下核心问题：

• 动态路由配置：无需重启的热更新
• 智能限流：自适应流量控制
• 统一鉴权：JWT与OAuth2.0集成
• 协议转换：REST/gRPC/GraphQL互转
• 监控告警：Prometheus指标采集

技术栈：ThinkPHP8.1 + Swoole + Redis + Nacos + Prometheus

二、环境准备与项目初始化

1. 创建ThinkPHP项目

composer create-project topthink/think api-gateway
cd api-gateway
composer require predis/predis swoole/ide-helper nacos/php-sdk

2. 目录结构规划

app/
├── controller/     # 控制器
├── gateway/        # 网关核心
│   ├── filter/     # 过滤器
│   ├── router/     # 路由解析
│   └── service/    # 网关服务
├── middleware/     # 中间件
├── model/          # 数据模型
config/
├── gateway.php     # 网关配置
├── route.php       # 路由配置
extend/
├── prometheus/     # 监控组件
public/
├── metrics         # 指标端点
runtime/
├── gateway/        # 运行时缓存

三、核心功能实现

1. 动态路由配置

// app/gateway/router/DynamicRouter.php
class DynamicRouter
{
    protected $routes = [];

    public function loadFromNacos()
    {
        $nacos = new NacosClient();
        $config = $nacos->getConfig('gateway_routes');

        $this->routes = json_decode($config, true);
    }

    public function dispatch($request)
    {
        $path = $request->path();
        $method = $request->method();

        foreach ($this->routes as $route) {
            if ($this->matchRoute($route, $path, $method)) {
                return $this->createResponse($route);
            }
        }

        throw new RouteNotFoundException();
    }

    protected function matchRoute($route, $path, $method)
    {
        // 实现路径匹配逻辑
    }
}

2. 智能限流中间件

// app/middleware/RateLimit.php
class RateLimit
{
    public function handle($request, Closure $next)
    {
        $route = $request->route();
        $clientIp = $request->ip();

        $limiter = new TokenBucket(
            $route->getRate(),
            $route->getBurst()
        );

        if (!$limiter->consume(1, $clientIp)) {
            return json([
                'code' => 429,
                'msg'  => '请求过于频繁'
            ]);
        }

        return $next($request);
    }
}

// TokenBucket算法实现
class TokenBucket
{
    public function consume($tokens, $key)
    {
        $redis = new Redis();
        $now = microtime(true);

        $rate = $this->rate / $this->capacity;
        $lastTime = $redis->hGet($key, 'last_time') ?: $now;
        $tokensLeft = $redis->hGet($key, 'tokens') ?: $this->capacity;

        $tokensLeft = min(
            $this->capacity,
            $tokensLeft + ($now - $lastTime) * $rate
        );

        if ($tokensLeft hMSet($key, [
            'last_time' => $now,
            'tokens' => $tokensLeft - $tokens
        ]);

        return true;
    }
}

四、统一鉴权系统

1. JWT认证服务

// app/gateway/service/AuthService.php
class AuthService
{
    public function authenticate($token)
    {
        try {
            $payload = JWT::decode($token, config('jwt.key'));

            return [
                'uid'   => $payload->uid,
                'roles' => $payload->roles,
                'exp'   => $payload->exp
            ];
        } catch (Exception $e) {
            throw new AuthFailedException();
        }
    }

    public function generateToken($user)
    {
        $payload = [
            'iss' => config('app.app_host'),
            'uid' => $user['id'],
            'roles' => $user['roles'],
            'iat' => time(),
            'exp' => time() + 3600
        ];

        return JWT::encode($payload, config('jwt.key'));
    }
}

2. 权限校验过滤器

// app/gateway/filter/AclFilter.php
class AclFilter
{
    public function check($request, $route)
    {
        $authHeader = $request->header('Authorization');
        $token = str_replace('Bearer ', '', $authHeader);

        $auth = app(AuthService::class)->authenticate($token);
        $requiredRoles = $route->getMetadata('roles', []);

        if (!array_intersect($requiredRoles, $auth['roles'])) {
            throw new ForbiddenException();
        }

        $request->user = $auth;
    }
}

五、协议转换引擎

1. REST转gRPC适配器

// app/gateway/service/GrpcAdapter.php
class GrpcAdapter
{
    public function transform($restRequest, $serviceConfig)
    {
        $grpcClient = new GrpcClient($serviceConfig['host']);

        $request = new $serviceConfig['request_class']();
        foreach ($serviceConfig['field_map'] as $rest => $grpc) {
            $setter = 'set' . ucfirst($grpc);
            $request->$setter($restRequest->param($rest));
        }

        list($response, $status) = $grpcClient->{$serviceConfig['method']}(
            $request,
            ['timeout' => 3000]
        )->wait();

        return $this->formatResponse($response);
    }
}

2. 响应统一格式化

// app/gateway/service/ResponseFormatter.php
class ResponseFormatter
{
    public function format($raw, $type)
    {
        switch ($type) {
            case 'json':
                return $this->formatJson($raw);
            case 'grpc':
                return $this->formatGrpc($raw);
            case 'graphql':
                return $this->formatGraphQL($raw);
            default:
                return $raw;
        }
    }

    protected function formatGrpc($response)
    {
        $result = [];
        foreach ($response->getFieldList() as $field) {
            $getter = 'get' . ucfirst($field);
            $result[$field] = $response->$getter();
        }

        return json($result);
    }
}

六、监控告警系统

1. Prometheus指标收集

// extend/prometheus/Metrics.php
class Metrics
{
    protected static $registry;

    public static function init()
    {
        self::$registry = new CollectorRegistry();

        self::$registry->registerGauge(
            'api_requests_total',
            'Total API requests',
            ['method', 'path', 'status']
        );

        self::$registry->registerHistogram(
            'api_response_time',
            'API response time',
            ['method', 'path'],
            [0.1, 0.5, 1, 2.5, 5]
        );
    }

    public static function observe($metric, $value, $labels = [])
    {
        self::$registry->getOrRegisterMetric($metric)
            ->observe($value, $labels);
    }
}

// 在中间件中记录指标
Metrics::observe('api_requests_total', 1, [
    $request->method(),
    $request->path(),
    $response->getCode()
]);

2. 告警规则配置

# prometheus/rules/api_gateway.rules.yml
groups:
- name: api_gateway
  rules:
  - alert: HighErrorRate
    expr: rate(api_requests_total{status=~"5.."}[1m]) > 0.1
    for: 5m
    labels:
      severity: critical
    annotations:
      summary: "High error rate on {{ $labels.path }}"
      description: "Error rate is {{ $value }}"

  - alert: SlowAPI
    expr: histogram_quantile(0.9, rate(api_response_time_bucket[1m])) > 2
    for: 10m
    labels:
      severity: warning

七、性能优化方案

1. Swoole协程优化

// config/swoole.php
return [
    'host'         => '0.0.0.0',
    'port'         => 9501,
    'mode'         => SWOOLE_PROCESS,
    'sock_type'    => SWOOLE_SOCK_TCP,
    'options'      => [
        'worker_num'       => swoole_cpu_num() * 2,
        'enable_coroutine' => true,
        'task_worker_num' => 4,
        'max_request'     => 10000,
    ]
];

// 协程MySQL客户端
Corun(function() {
    $mysql = new SwooleCoroutineMySQL();
    $mysql->connect([
        'host' => '127.0.0.1',
        'user' => 'root',
        'password' => '',
        'database' => 'test'
    ]);

    $result = $mysql->query('SELECT * FROM users');
});

2. 路由缓存预热

// app/command/RouteCache
class RouteCache extends Command
{
    protected function configure()
    {
        $this->setName('route:cache');
    }

    protected function execute(Input $input, Output $output)
    {
        $router = app(Route::class);
        $routes = $router->getRouteList();

        $cache = [];
        foreach ($routes as $route) {
            $cache[$route->getRule()] = [
                'path'   => $route->getRoute(),
                'method' => $route->getMethod(),
                'option' => $route->getOption()
            ];
        }

        file_put_contents(
            runtime_path('gateway/route.cache'),
            serialize($cache)
        );
    }
}

八、总结与扩展

通过本教程，您已经掌握了：

1. API网关的核心架构设计
2. ThinkPHP8的高阶应用
3. 微服务通信协议转换
4. 高并发场景下的性能优化

扩展学习方向：

• 服务网格(Service Mesh)集成
• 全链路灰度发布
• API编排引擎
• Wasm插件系统
