Vue3企业级中台系统实战：从微前端架构到可视化大屏全栈开发

发布日期：2024年7月25日

一、系统架构设计

本教程将构建一个完整的企业级中台系统，采用微前端架构：

主应用：Vue3 + TypeScript核心框架
微应用：React/Vue2/Vue3多技术栈集成
状态管理：Pinia + 共享状态方案
权限控制：RBAC动态路由系统
数据可视化：ECharts + Three.js大屏

技术栈：Vue3 + TypeScript + Pinia + Qiankun + ECharts

二、项目初始化与配置

1. 创建主应用

# 使用Vite创建Vue3项目
npm create vite@latest main-app --template vue-ts
cd main-app

# 安装核心依赖
npm install pinia qiankun axios echarts
npm install -D @types/node

2. 目录结构规划

src/
├── apis/              # 接口服务
├── components/        # 公共组件
├── micro-apps/        # 微应用配置
├── router/            # 路由配置
│   └── permission.ts  # 权限控制
├── stores/            # Pinia状态
│   ├── app.ts         # 应用状态
│   └── user.ts        # 用户状态
├── styles/            # 全局样式
├── utils/             # 工具函数
├── views/             # 页面组件
│   ├── dashboard/     # 数据大屏
│   └── layout/        # 布局组件
├── App.vue
└── main.ts

三、微前端集成

1. 主应用配置

// micro-apps/index.ts
import { registerMicroApps, start } from 'qiankun'

const apps = [
  {
    name: 'react-app',
    entry: '//localhost:7101',
    container: '#subapp-container',
    activeRule: '/react',
    props: {
      baseApi: import.meta.env.VITE_API_URL,
      token: localStorage.getItem('token')
    }
  },
  {
    name: 'vue2-app',
    entry: '//localhost:7102',
    container: '#subapp-container',
    activeRule: '/vue2'
  }
]

export function registerApps() {
  registerMicroApps(apps)
  start({
    prefetch: true,
    sandbox: {
      strictStyleIsolation: true,
      experimentalStyleIsolation: true
    }
  })
}

2. 子应用适配(Vue3)

// 子应用入口文件
import { createApp } from 'vue'
import App from './App.vue'
import { renderWithQiankun, qiankunWindow } from 'vite-plugin-qiankun/dist/helper'

let app: App

function render(props: any = {}) {
  const { container } = props
  app = createApp(App)
  app.mount(container?.querySelector('#app') || '#app')
}

renderWithQiankun({
  mount(props) {
    render(props)
  },
  bootstrap() {
    console.log('bootstrap')
  },
  unmount() {
    app.unmount()
  }
})

if (!qiankunWindow.__POWERED_BY_QIANKUN__) {
  render()
}

四、权限控制系统

1. 动态路由实现

// router/permission.ts
import { RouteRecordRaw } from 'vue-router'
import { useUserStore } from '@/stores/user'

export async function generateRoutes(): Promise {
  const userStore = useUserStore()
  if (!userStore.roles.length) {
    await userStore.fetchUserInfo()
  }

  const permissionRoutes: RouteRecordRaw[] = []

  // 根据角色过滤路由
  userStore.roles.forEach(role => {
    const routes = asyncRoutes.filter(route => {
      return route.meta?.roles?.includes(role)
    })
    permissionRoutes.push(...routes)
  })

  return permissionRoutes
}

// 路由守卫
router.beforeEach(async (to, from, next) => {
  if (to.meta.requiresAuth && !useUserStore().token) {
    next(`/login?redirect=${to.path}`)
    return
  }

  if (!router.hasRoute(to.name!)) {
    const routes = await generateRoutes()
    routes.forEach(route => router.addRoute(route))
    next(to.fullPath)
    return
  }

  next()
})

2. 权限指令

// directives/permission.ts
import { Directive } from 'vue'
import { useUserStore } from '@/stores/user'

export const permission: Directive = {
  mounted(el, binding) {
    const { value } = binding
    const userStore = useUserStore()

    if (value && Array.isArray(value)) {
      const hasPermission = userStore.roles.some(role => {
        return value.includes(role)
      })

      if (!hasPermission) {
        el.parentNode?.removeChild(el)
      }
    } else {
      throw new Error('权限指令需要传入数组，例如 v-permission="['admin']"')
    }
  }
}

五、可视化大屏开发

1. ECharts组件封装

<script setup lang="ts">
import * as echarts from 'echarts'
import { onMounted, onUnmounted, ref, watch } from 'vue'

const props = defineProps<{
  options: echarts.EChartsOption
  theme?: string
  width?: string
  height?: string
}>()

const chartRef = ref<HTMLElement>()
let chart: echarts.ECharts | null = null

const initChart = () => {
  if (!chartRef.value) return

  chart = echarts.init(chartRef.value, props.theme)
  chart.setOption(props.options)

  const resize = () => chart?.resize()
  window.addEventListener('resize', resize)

  onUnmounted(() => {
    window.removeEventListener('resize', resize)
    chart?.dispose()
  })
}

watch(() => props.options, (newVal) => {
  chart?.setOption(newVal)
}, { deep: true })

onMounted(initChart)
</script>

<template>
  <div ref="chartRef" :style="{ width, height }"></div>
</template>

2. 实时数据大屏

// views/dashboard/RealtimeDashboard.vue
import { useWebSocket } from '@/utils/websocket'
import { ref } from 'vue'

const metrics = ref({
  userCount: 0,
  orderCount: 0,
  revenue: 0
})

const { connect } = useWebSocket('dashboard', {
  onMessage(data) {
    metrics.value = {
      userCount: data.current_users,
      orderCount: data.orders_today,
      revenue: data.daily_revenue
    }
    updateCharts(data)
  }
})

onMounted(() => {
  connect()
  fetchInitialData()
})

六、状态管理方案

1. Pinia模块化设计

// stores/app.ts
import { defineStore } from 'pinia'

export const useAppStore = defineStore('app', {
  state: () => ({
    sidebarCollapsed: false,
    theme: 'light',
    microApps: []
  }),
  actions: {
    toggleSidebar() {
      this.sidebarCollapsed = !this.sidebarCollapsed
    },
    async fetchMicroApps() {
      const res = await api.getMicroApps()
      this.microApps = res.data
    }
  },
  persist: {
    enabled: true,
    strategies: [
      {
        key: 'app',
        storage: localStorage
      }
    ]
  }
})

2. 跨应用状态共享

// stores/shared.ts
import { defineStore } from 'pinia'

export const useSharedStore = defineStore('shared', {
  state: () => ({
    globalUser: null,
    notifications: []
  }),
  actions: {
    setGlobalUser(user) {
      this.globalUser = user
      // 通过qiankun通信
      if (window.__POWERED_BY_QIANKUN__) {
        window.dispatchEvent(new CustomEvent('global-user-change', {
          detail: user
        }))
      }
    }
  }
})

// 主应用中监听状态变化
window.addEventListener('global-user-change', (e) => {
  useSharedStore().setGlobalUser(e.detail)
})

七、性能优化实践

1. 组件懒加载

// router/index.ts
const routes: RouteRecordRaw[] = [
  {
    path: '/dashboard',
    component: () => import(/* webpackChunkName: "dashboard" */ '@/views/Dashboard.vue'),
    meta: { requiresAuth: true }
  },
  {
    path: '/user/:id',
    component: () => import(/* webpackChunkName: "user" */ '@/views/UserDetail.vue')
  }
]

2. 虚拟滚动优化

<template>
  <VirtualList
    :data="largeList"
    :item-size="60"
    :height="500"
  >
    <template #default="{ item }">
      <UserCard :user="item" />
    </template>
  </VirtualList>
</template>

<script setup>
import { ref } from 'vue'
import VirtualList from '@/components/VirtualList.vue'
import { fetchLargeData } from '@/api'

const largeList = ref([])

fetchLargeData().then(data => {
  largeList.value = data
})
</script>
