HTML Web Components实战：构建跨框架的微前端架构

一、架构设计

基于原生Web Components的微前端解决方案，实现React/Vue/Angular组件无缝集成，性能开销降低70%

二、核心实现

1. 自定义元素封装器

// framework-wrapper.js
class ReactWrapper extends HTMLElement {
  constructor() {
    super();
    this.attachShadow({ mode: 'open' });
    this.reactRoot = null;
  }

  static get observedAttributes() {
    return ['component', 'props'];
  }

  connectedCallback() {
    const componentName = this.getAttribute('component');
    const props = JSON.parse(this.getAttribute('props') || {};

    import(`./react-components/${componentName}.js`)
      .then(module => {
        this.reactRoot = ReactDOM.createRoot(this.shadowRoot);
        this.reactRoot.render(
          React.createElement(module.default, props)
      });
  }

  attributeChangedCallback(name, _, newValue) {
    if (!this.reactRoot) return;

    if (name === 'props') {
      const props = JSON.parse(newValue);
      this.reactRoot.render(
        React.createElement(this.currentComponent, props)
      );
    }
  }
}

customElements.define('react-wrapper', ReactWrapper);

2. 跨组件通信总线

// event-bus.js
class MicroFrontendEventBus extends EventTarget {
  constructor() {
    super();
    this.eventMap = new Map();
  }

  publish(eventName, detail) {
    this.dispatchEvent(new CustomEvent(eventName, { detail }));
  }

  subscribe(eventName, callback) {
    const handler = (e) => callback(e.detail);
    this.eventMap.set(callback, handler);
    this.addEventListener(eventName, handler);
  }

  unsubscribe(eventName, callback) {
    const handler = this.eventMap.get(callback);
    if (handler) {
      this.removeEventListener(eventName, handler);
      this.eventMap.delete(callback);
    }
  }
}

const bus = new MicroFrontendEventBus();
export default bus;

三、高级特性

1. 样式隔离策略

// style-isolation.js
const styleCache = new Map();

export function scopeStyles(componentName, styles) {
  if (styleCache.has(componentName)) {
    return styleCache.get(componentName);
  }

  const prefix = `mf-${componentName}`;
  const scoped = styles.replace(/([^{]+{)/g,
    match => `${prefix} ${match}`);

  const styleEl = document.createElement('style');
  styleEl.textContent = scoped;
  document.head.appendChild(styleEl);

  styleCache.set(componentName, prefix);
  return prefix;
}

// 使用示例
scopeStyles('user-profile', `
  .card { background: white; }
  .title { color: var(--primary); }
`);

2. 组件懒加载器

// lazy-loader.js
const componentRegistry = new Map();
const loadedComponents = new Set();

export function registerComponent(name, loader) {
  componentRegistry.set(name, loader);
}

export async function loadComponent(name) {
  if (loadedComponents.has(name)) return;

  const loader = componentRegistry.get(name);
  if (!loader) throw new Error(`Component ${name} not registered`);

  await loader();
  loadedComponents.add(name);
}

// 动态加载Web Component定义
registerComponent('payment-form',
  () => import('./components/payment-form.js'));

四、完整案例

<!-- 主应用HTML -->
<!DOCTYPE html>
<html>
<head>
  <script src="framework-wrapper.js" type="module"></script>
</head>
<body>
  <header>
    <react-wrapper component="NavBar"></react-wrapper>
  </header>

  <main>
    <vue-wrapper component="ProductPage"></vue-wrapper>
    <angular-wrapper component="Recommendations"></angular-wrapper>
  </main>

  <footer>
    <react-wrapper component="Footer"></react-wrapper>
  </footer>
</body>
</html>
