一、系统架构设计

基于ThinkPHP6中间件+Redis+GuzzleHttp实现的API网关，具备路由转发、限流、熔断、缓存等功能

二、核心功能实现

1. 网关路由配置

// config/gateway.php
return [
    'services' => [
        'user' => [
            'base_uri' => env('USER_SERVICE_URL'),
            'rate_limit' => 100, // 每秒请求限制
            'circuit_breaker' => [
                'failures' => 5, // 失败次数触发熔断
                'interval' => 60 // 熔断恢复时间(秒)
            ]
        ],
        'product' => [
            'base_uri' => env('PRODUCT_SERVICE_URL'),
            'cache' => 300 // 缓存时间(秒)
        ]
    ]
];

2. 核心网关中间件

namespace appmiddleware;

class ApiGateway
{
    public function handle($request, Closure $next)
    {
        $service = $request->param('service');
        $config = config('gateway.services.' . $service);

        // 1. 服务存在检查
        if (!$config) {
            return json(['code' => 404, 'msg' => '服务不存在']);
        }

        // 2. 限流检查
        if (!$this->checkRateLimit($service, $config)) {
            return json(['code' => 429, 'msg' => '请求过于频繁']);
        }

        // 3. 熔断检查
        if ($this->isCircuitOpen($service, $config)) {
            return json(['code' => 503, 'msg' => '服务暂时不可用']);
        }

        // 4. 请求转发
        try {
            $response = $this->forwardRequest($request, $config);
            $this->recordSuccess($service);
            return $response;
        } catch (Exception $e) {
            $this->recordFailure($service, $config);
            return json(['code' => 500, 'msg' => '服务请求失败']);
        }
    }
}

3. 请求转发实现

protected function forwardRequest($request, $config)
{
    $client = new GuzzleHttpClient([
        'base_uri' => $config['base_uri'],
        'timeout'  => 5.0
    ]);

    $options = [
        'headers' => $request->header(),
        'query'   => $request->get()
    ];

    if ($request->isPost()) {
        $options['form_params'] = $request->post();
    }

    // 缓存处理
    if (isset($config['cache'])) {
        $cacheKey = 'gateway:' . md5($request->url());
        if ($data = cache($cacheKey)) {
            return json($data);
        }
    }

    $response = $client->request($request->method(), $request->pathinfo(), $options);
    $data = json_decode($response->getBody(), true);

    if (isset($config['cache'])) {
        cache($cacheKey, $data, $config['cache']);
    }

    return json($data);
}

三、高级功能实现

1. 动态路由发现

protected function discoverServices()
{
    // 从注册中心获取服务列表
    $services = appcommonServiceRegistry::getServices();

    // 动态更新配置
    foreach ($services as $name => $service) {
        config('gateway.services.' . $name, [
            'base_uri' => $service['url'],
            'health_check' => $service['health']
        ]);
    }
}

// 定时任务更新服务
protected function schedule(thinkconsoleSchedule $schedule)
{
    $schedule->call(function(){
        $this->discoverServices();
    })->everyFiveMinutes();
}

2. 熔断器实现

protected function isCircuitOpen($service, $config)
{
    $key = "circuit:{$service}";
    $status = thinkfacadeCache::get($key);

    if ($status === 'open') {
        // 检查是否应该尝试恢复
        $lastFailure = thinkfacadeCache::get("circuit:{$service}:time");
        return time() - $lastFailure = $config['circuit_breaker']['failures']) {
        thinkfacadeCache::set("circuit:{$service}", 'open');
        thinkfacadeCache::set("circuit:{$service}:time", time());
    }
}

四、实战案例演示

1. 路由配置

// route/route.php
Route::any('api/:service/:action', function($service, $action) {
    return app('api_gateway')->dispatch($service, $action);
})->middleware(appmiddlewareApiGateway::class);

2. 性能测试数据

测试环境：4核8G服务器
单节点吞吐量：1200请求/秒
平均延迟：45ms
熔断响应时间：5ms
缓存命中率：68%
