ThinkPHP6+WebSocket实现实时聊天系统全栈开发指南

2025-08-01 0 359

ThinkPHP6+WebSocket实现实时聊天系统全栈开发指南

一、系统架构设计

本系统采用前后端分离架构:

  • 后端服务:ThinkPHP6 + Swoole WebSocket
  • 前端界面:Vue.js + WebSocket客户端
  • 数据存储:MySQL + Redis
  • 消息协议:自定义JSON格式

二、环境准备与配置

1. 安装Swoole扩展

pecl install swoole

在php.ini中添加:

extension=swoole.so

2. 创建ThinkPHP6项目

composer create-project topthink/think tp6-chat
cd tp6-chat
composer require topthink/think-swoole

三、WebSocket服务实现

1. 创建WebSocket服务类

app/service/WebSocketService.php:

<?php
namespace appservice;

use SwooleWebSocketServer;
use thinkfacadeCache;

class WebSocketService
{
    private $server;
    private $config = [
        'host' => '0.0.0.0',
        'port' => 9502,
        'options' => [
            'worker_num' => 4,
            'daemonize' => false,
            'max_request' => 1000
        ]
    ];

    public function __construct()
    {
        $this->server = new Server(
            $this->config['host'],
            $this->config['port']
        );

        $this->server->set($this->config['options']);
    }

    public function start()
    {
        $this->server->on('open', function (Server $server, $request) {
            $userId = $request->get['uid'];
            Cache::set('ws_user_' . $userId, $request->fd);
        });

        $this->server->on('message', function (Server $server, $frame) {
            $data = json_decode($frame->data, true);
            $this->handleMessage($data);
        });

        $this->server->on('close', function (Server $server, $fd) {
            Cache::delete('ws_fd_' . $fd);
        });

        $this->server->start();
    }

    private function handleMessage($data)
    {
        switch ($data['type']) {
            case 'private':
                $this->sendPrivateMessage($data);
                break;
            case 'group':
                $this->sendGroupMessage($data);
                break;
        }
    }

    private function sendPrivateMessage($data)
    {
        $toFd = Cache::get('ws_user_' . $data['to']);
        if ($toFd) {
            $this->server->push($toFd, json_encode([
                'type' => 'message',
                'from' => $data['from'],
                'content' => $data['content'],
                'time' => date('Y-m-d H:i:s')
            ]));
        }
    }
}

四、业务逻辑整合

1. 用户认证中间件

app/middleware/Auth.php:

<?php
namespace appmiddleware;

use appserviceJwtService;

class Auth
{
    public function handle($request, Closure $next)
    {
        $token = $request->header('Authorization');
        if (!$payload = JwtService::verify($token)) {
            return json(['code' => 401, 'msg' => '认证失败']);
        }

        $request->user = $payload;
        return $next($request);
    }
}

2. 消息控制器

app/controller/Message.php:

<?php
namespace appcontroller;

use thinkRequest;
use appmodelMessage as MessageModel;
use appserviceWebSocketClient;

class Message
{
    public function send(Request $request)
    {
        $data = $request->post();
        $message = MessageModel::create([
            'from_id' => $request->user->id,
            'to_id' => $data['to_id'],
            'content' => $data['content'],
            'type' => $data['type']
        ]);

        WebSocketClient::send([
            'type' => 'private',
            'from' => $request->user->id,
            'to' => $data['to_id'],
            'content' => $data['content']
        ]);

        return json(['code' => 200, 'data' => $message]);
    }
}

五、前端实现关键代码

1. WebSocket客户端连接

const socket = new WebSocket(`ws://${location.hostname}:9502?uid=${userId}`);

socket.onmessage = function(event) {
    const data = JSON.parse(event.data);
    switch(data.type) {
        case 'message':
            addMessageToChat(data);
            break;
        case 'notification':
            showNotification(data);
            break;
    }
};

function sendMessage(content, toId) {
    socket.send(JSON.stringify({
        type: 'private',
        from: currentUser.id,
        to: toId,
        content: content
    }));
}

六、系统优化与扩展

  1. 心跳检测:防止连接意外断开
  2. 消息队列:使用Redis处理高并发消息
  3. 消息持久化:异步存储聊天记录
  4. 分布式部署:多节点WebSocket服务
  5. 消息加密:保障通信安全
