Vue3动态表单引擎开发实战：JSON Schema驱动的高效表单解决方案 | 前端架构设计

一、动态表单系统架构设计

现代企业级表单系统需要解决的核心问题：

• 动态渲染：根据配置实时生成表单界面
• 数据校验：支持复杂校验规则
• 布局控制：灵活的表单布局管理
• 状态管理：处理复杂表单数据流
• 扩展机制：支持自定义表单控件

系统架构图

Schema解析器 → 表单渲染引擎 → 状态管理 → 校验引擎
    ↑               ↑               ↑           ↑
JSON Schema    基础组件库      全局状态      校验规则


二、核心模块实现

1. Schema解析器

<script setup>
import { ref, computed } from 'vue'

const props = defineProps({
  schema: {
    type: Object,
    required: true
  }
})

// 解析Schema生成表单配置
const formConfig = computed(() => {
  return {
    fields: parseFields(props.schema.properties),
    layout: props.schema.layout || 'vertical'
  }
})

function parseFields(properties) {
  return Object.entries(properties).map(([name, config]) => {
    return {
      name,
      label: config.title || name,
      type: config.type || 'text',
      component: getComponent(config.type),
      rules: generateRules(config),
      options: config.enum || []
    }
  })
}

function getComponent(type) {
  const componentMap = {
    string: 'InputText',
    number: 'InputNumber',
    boolean: 'InputSwitch',
    array: 'InputSelect'
  }
  return componentMap[type] || 'InputText'
}
</script>

2. 动态表单渲染器

<template>
  <form class="dynamic-form" :class="`layout-${formConfig.layout}`">
    <template v-for="field in formConfig.fields" :key="field.name">
      <component
        :is="field.component"
        v-model="formData[field.name]"
        :label="field.label"
        :options="field.options"
        :rules="field.rules"
      />
    </template>
  </form>
</template>

<script setup>
import { defineProps, ref } from 'vue'
import InputText from './components/InputText.vue'
import InputNumber from './components/InputNumber.vue'
// 导入其他基础组件...

defineProps({
  formConfig: {
    type: Object,
    required: true
  }
})

const formData = ref({})
</script>

三、高级功能实现

1. 条件渲染逻辑

// 在parseFields函数中添加条件渲染支持
function parseFields(properties) {
  return Object.entries(properties).map(([name, config]) => {
    return {
      // ...其他配置
      visible: config.visible || true,
      dependencies: config.dependencies || [],
      condition: config.condition || null
    }
  })
}

// 在组件中添加条件渲染逻辑
const visibleFields = computed(() => {
  return formConfig.value.fields.filter(field => {
    if (!field.dependencies.length) return field.visible

    const dependsValues = field.dependencies.reduce((obj, dep) => {
      obj[dep] = formData.value[dep]
      return obj
    }, {})

    return evaluateCondition(field.condition, dependsValues)
  })
})

function evaluateCondition(condition, values) {
  if (!condition) return true
  // 实现条件表达式解析逻辑
  // 示例：return new Function(`return ${condition}`).call(values)
}

2. 复杂校验系统

function generateRules(config) {
  const rules = []

  if (config.required) {
    rules.push({
      required: true,
      message: `${config.title || '该字段'}是必填项`,
      trigger: 'blur'
    })
  }

  if (config.pattern) {
    rules.push({
      pattern: new RegExp(config.pattern),
      message: config.message || '格式不正确',
      trigger: 'blur'
    })
  }

  if (config.validator) {
    rules.push({
      validator: (rule, value) => {
        return new Promise((resolve) => {
          // 执行自定义校验逻辑
          const valid = config.validator(value)
          if (valid) resolve()
          else reject(new Error(config.message || '校验失败'))
        })
      },
      trigger: 'change'
    })
  }

  return rules
}

// 在表单组件中使用校验
const formRef = ref(null)

const validate = async () => {
  try {
    await formRef.value.validate()
    return true
  } catch (e) {
    console.error('表单校验失败', e)
    return false
  }
}

四、性能优化策略

1. 表单数据响应式优化

import { shallowRef, triggerRef } from 'vue'

// 使用shallowRef减少不必要的响应式开销
const formData = shallowRef({})

// 批量更新表单数据
function setFormData(data) {
  formData.value = { ...data }
  triggerRef(formData)
}

// 单个字段更新优化
function updateField(name, value) {
  const newData = { ...formData.value, [name]: value }
  formData.value = newData
  // 不需要triggerRef，因为解构创建了新对象
}

2. 动态组件懒加载

const componentMap = {
  InputText: defineAsyncComponent(() => import('./InputText.vue')),
  InputNumber: defineAsyncComponent(() => import('./InputNumber.vue')),
  // 其他组件...
}

function getComponent(type) {
  return componentMap[type] || componentMap.InputText
}

五、扩展机制设计

1. 自定义组件注册

// 组件注册管理器
const customComponents = new Map()

export function registerComponent(type, component) {
  customComponents.set(type, component)
}

export function getComponent(type) {
  return customComponents.get(type) || defaultComponents.get(type)
}

// 使用示例
import CustomUploader from './CustomUploader.vue'
registerComponent('uploader', CustomUploader)

2. 插件系统实现

// 插件接口定义
export function createFormPlugin(plugin) {
  return {
    install(formEngine) {
      if (plugin.components) {
        Object.entries(plugin.components).forEach(([name, component]) => {
          formEngine.registerComponent(name, component)
        })
      }

      if (plugin.mixins) {
        formEngine.addMixins(plugin.mixins)
      }
    }
  }
}

// 插件使用示例
const richTextPlugin = createFormPlugin({
  components: {
    richText: RichTextEditor
  },
  mixins: [{
    beforeSubmit(formData) {
      // 提交前处理逻辑
    }
  }]
})

formEngine.use(richTextPlugin)

六、实战案例：用户注册表单

1. Schema定义

const registerSchema = {
  title: "用户注册",
  layout: "vertical",
  properties: {
    username: {
      type: "string",
      title: "用户名",
      minLength: 4,
      maxLength: 16,
      pattern: "^[a-zA-Z0-9_]+$",
      required: true
    },
    password: {
      type: "string",
      title: "密码",
      format: "password",
      minLength: 6,
      required: true
    },
    confirmPassword: {
      type: "string",
      title: "确认密码",
      format: "password",
      dependencies: ["password"],
      condition: "values.password === value",
      required: true
    },
    // 更多字段...
  }
}

2. 表单使用

<template>
  <DynamicForm
    :schema="registerSchema"
    @submit="handleSubmit"
  />
</template>

<script setup>
import { ref } from 'vue'
import DynamicForm from './DynamicForm.vue'

const registerSchema = ref({/* 同上 */})

const handleSubmit = async (formData) => {
  const res = await api.register(formData)
  // 处理注册结果
}
</script>
