一、架构设计

基于JSON Schema+Vue动态组件+自定义指令的表单系统，支持100+表单元素的动态渲染

二、核心实现

// form-engine.js
export default {
  props: {
    schema: {
      type: Object,
      required: true
    },
    model: {
      type: Object,
      required: true
    }
  },

  render(h) {
    const renderField = (field) => {
      const componentMap = {
        'input': 'el-input',
        'select': 'el-select',
        'checkbox': 'el-checkbox-group',
        // 更多组件映射...
      };

      return h(componentMap[field.type], {
        props: {
          value: this.model[field.model],
          ...field.props
        },
        on: {
          input: (val) => this.$set(this.model, field.model, val)
        },
        directives: [
          {
            name: 'validate',
            value: field.rules
          }
        ]
      }, [
        field.type === 'select' ?
          field.options.map(opt =>
            h('el-option', { props: { label: opt.label, value: opt.value } })
          : null
      ]);
    };

    return h('div', this.schema.fields.map(renderField));
  }
};

// validate.js
export default {
  inserted(el, binding, vnode) {
    const rules = binding.value;
    const field = vnode.componentInstance;

    field.$on('blur', () => {
      const value = field.value;
      const errors = [];

      rules.forEach(rule => {
        if (rule.required && !value) {
          errors.push(rule.message || '必填字段');
        }
        if (rule.pattern && !rule.pattern.test(value)) {
          errors.push(rule.message || '格式错误');
        }
        // 更多验证规则...
      });

      if (errors.length) {
        field.$parent.$emit('validate-error', {
          field: field.field,
          errors
        });
      }
    });
  }
};

三、高级特性

// 在form-engine.js中添加
watch: {
  model: {
    deep: true,
    handler() {
      this.schema.fields.forEach(field => {
        if (field.showIf) {
          const shouldShow = new Function(
            'model',
            `return ${field.showIf}`
          )(this.model);
          this.$set(field, '_visible', shouldShow);
        }
      });
    }
  }
},

// 修改renderField方法
const renderField = (field) => {
  if (field._visible === false) return null;
  // 原有渲染逻辑...
};

// form-designer.vue
export default {
  data() {
    return {
      currentSchema: {
        fields: []
      },
      fieldTypes: [
        { label: '文本输入', value: 'input' },
        { label: '下拉选择', value: 'select' },
        // 更多字段类型...
      ]
    };
  },

  methods: {
    addField(type) {
      this.currentSchema.fields.push({
        type,
        model: `field_${Date.now()}`,
        label: '新字段',
        props: {},
        rules: []
      });
    },

    generateSchema() {
      return JSON.parse(JSON.stringify(this.currentSchema));
    }
  }
};

四、完整案例

<template>
  <div>
    <form-engine
      :schema="formSchema"
      :model="formData"
      @validate-error="handleError" />

    <pre>{{ formData }}</pre>
  </div>
</template>

<script>
export default {
  data() {
    return {
      formSchema: {
        fields: [
          {
            type: 'input',
            model: 'username',
            label: '用户名',
            rules: [
              { required: true, message: '请输入用户名' },
              { pattern: /^[a-z0-9]+$/, message: '只能包含小写字母和数字' }
            ]
          },
          {
            type: 'select',
            model: 'gender',
            label: '性别',
            options: [
              { label: '男', value: 'male' },
              { label: '女', value: 'female' }
            ]
          }
        ]
      },
      formData: {}
    };
  },

  methods: {
    handleError({ field, errors }) {
      this.$message.error(`${field}验证失败: ${errors.join(',')}`);
    }
  }
};
</script>
