UniApp跨平台开发实战：从零打造智能家居控制APP | 全栈解决方案

一、项目架构设计

本教程将开发一个完整的智能家居控制应用，支持以下功能：

• 多端适配：iOS/Android/小程序/H5
• 设备管理：蓝牙/WiFi设备连接
• 实时控制：WebSocket即时通信
• 场景联动：自动化规则引擎
• 数据可视化：Echarts图表集成

技术栈：UniApp + Vue3 + uView UI + MQTT + ECharts

二、环境准备与项目初始化

1. 创建UniApp项目

# 使用Vue3/Vite模板
npx degit dcloudio/uni-preset-vue#vite my-smart-home

# 安装依赖
cd my-smart-home
npm install
npm install uview-ui mqtt echarts

2. 目录结构规划

src/
├── api/               # 接口服务
├── components/        # 公共组件
├── composables/       # Vue组合式API
├── pages/             # 页面组件
├── static/            # 静态资源
├── store/             # Pinia状态管理
├── styles/            # 全局样式
├── utils/             # 工具函数
├── App.vue            # 应用入口
└── main.js            # 主配置文件

三、核心功能实现

1. 多端设备连接

// utils/device-connector.js
export function connectBluetoothDevice() {
  return new Promise((resolve, reject) => {
    uni.openBluetoothAdapter({
      success: (res) => {
        uni.startBluetoothDevicesDiscovery({
          services: ['0000FFE0-0000-1000-8000-00805F9B34FB'],
          success: (discoveryRes) => {
            uni.onBluetoothDeviceFound((foundRes) => {
              const device = foundRes.devices.find(d =>
                d.name.startsWith('SMART_'));
              if (device) {
                uni.stopBluetoothDevicesDiscovery();
                resolve(device);
              }
            });
          }
        });
      },
      fail: reject
    });
  });
}

// WiFi设备连接
export function connectWifiDevice(ssid, password) {
  return uni.connectWifi({
    SSID: ssid,
    password: password,
    BSSID: ''
  });
}

2. MQTT实时通信

// composables/useMqtt.js
import mqtt from 'mqtt/dist/mqtt.min';

export function useMqtt() {
  const client = ref(null);
  const messages = ref([]);

  const connect = (options) => {
    client.value = mqtt.connect('wxs://iot.example.com/mqtt', {
      clientId: `client_${Date.now()}`,
      username: 'smart_home',
      password: 'secure_password',
      ...options
    });

    client.value.on('connect', () => {
      uni.showToast({ title: '设备已连接', icon: 'success' });
    });

    client.value.on('message', (topic, payload) => {
      messages.value.push({
        topic,
        payload: JSON.parse(payload.toString())
      });
    });
  };

  const subscribe = (topic) => {
    client.value?.subscribe(topic, { qos: 1 });
  };

  const publish = (topic, message) => {
    client.value?.publish(topic, JSON.stringify(message));
  };

  return { client, messages, connect, subscribe, publish };
}

四、UI组件开发

1. 设备控制卡片

<template>
  <view class="device-card" :class="{ 'active': device.status }">
    <u-icon :name="device.icon" size="28"></u-icon>
    <text class="name">{{ device.name }}</text>
    <u-switch
      v-model="device.status"
      @change="handleDeviceToggle"
      active-color="#07c160"
    ></u-switch>
  </view>
</template>

<script setup>
const props = defineProps({
  device: {
    type: Object,
    required: true
  }
});

const handleDeviceToggle = (value) => {
  uni.showLoading({ title: '控制中...' });
  publish(`device/${props.device.id}/control`, {
    command: value ? 'ON' : 'OFF'
  });
};
</script>

2. 场景自动化编辑器

<template>
  <view class="scene-editor">
    <draggable
      v-model="triggers"
      group="triggers"
      handle=".drag-handle"
    >
      <view
        v-for="(trigger, index) in triggers"
        :key="index"
        class="trigger-item"
      >
        <u-icon name="list-dot" class="drag-handle"></u-icon>
        <trigger-config :model="trigger" />
        <u-icon
          name="trash"
          @click="removeTrigger(index)"
        ></u-icon>
      </view>
    </draggable>

    <u-button @click="addTrigger">添加触发条件</u-button>
  </view>
</template>

五、多端适配方案

1. 条件编译处理

// 平台特定代码处理
function shareDevice(device) {
  // #ifdef MP-WEIXIN
  wx.shareAppMessage({
    title: `分享${device.name}控制权限`,
    path: `/pages/device/share?id=${device.id}`
  });
  // #endif

  // #ifdef APP-PLUS
  plus.share.sendWithSystem({
    type: 'text',
    content: `设备分享：${device.name}`
  });
  // #endif

  // #ifdef H5
  navigator.clipboard.writeText(
    `${location.origin}/#/pages/device/share?id=${device.id}`
  );
  uni.showToast({ title: '链接已复制' });
  // #endif
}

2. 响应式布局设计

<template>
  <view class="dashboard">
    <view class="grid" :style="gridStyle">
      <device-card
        v-for="device in devices"
        :key="device.id"
        :device="device"
      />
    </view>
  </view>
</template>

<script setup>
import { computed } from 'vue';
import { useWindowSize } from '@vueuse/core';

const { width } = useWindowSize();

const gridStyle = computed(() => {
  const columnWidth = width.value > 768 ? 200 : 150;
  const columns = Math.floor(width.value / columnWidth);
  return {
    'grid-template-columns': `repeat(${columns}, 1fr)`
  };
});
</script>

六、性能优化实践

1. 图片懒加载

<template>
  <image
    :src="placeholder"
    :lazy-load="true"
    :data-src="realSrc"
    @load="handleImageLoad"
    @error="handleImageError"
  />
</template>

<script setup>
const props = defineProps({
  src: String
});

const realSrc = ref('');
const placeholder = '/static/placeholder.png';

const handleImageLoad = (e) => {
  const observer = uni.createIntersectionObserver(this);
  observer.relativeToViewport();
  observer.observe('.lazy-image', (res) => {
    if (res.intersectionRatio > 0) {
      realSrc.value = props.src;
      observer.disconnect();
    }
  });
};
</script>

2. 数据缓存策略

// utils/cache.js
export function createCacheWrapper(fn, key, ttl = 300) {
  return async (...args) => {
    try {
      const cached = uni.getStorageSync(key);
      if (cached && Date.now() - cached.timestamp  {
  const res = await uni.request({ url: '/api/devices' });
  return res.data;
}, 'device_list', 600);

七、打包发布流程

1. 多平台构建命令

# 微信小程序
npm run build:mp-weixin

# H5
npm run build:h5

# Android App
npm run build:app-plus &&
cd dist/build/app-plus &&
zip -r ../android.zip ./*

# iOS App (需Xcode)
npm run build:app-plus &&
open /dist/build/app-plus/ios

2. 自动化部署配置

# .github/workflows/deploy.yml
name: Deploy

on:
  push:
    branches: [main]

jobs:
  build:
    runs-on: ubuntu-latest

    steps:
    - uses: actions/checkout@v2

    - name: Setup Node
      uses: actions/setup-node@v2
      with:
        node-version: '16'

    - name: Install dependencies
      run: npm install

    - name: Build for WeChat
      run: npm run build:mp-weixin

    - name: Deploy to CDN
      uses: actions/upload-artifact@v2
      with:
        name: weapp-build
        path: dist/build/mp-weixin

八、总结与扩展

通过本教程，您已经掌握了：

1. UniApp跨平台开发全流程
2. 物联网设备连接与控制
3. 实时通信与状态管理
4. 多端适配与性能优化

扩展学习方向：

• UniApp插件开发
• 原生能力扩展（Android/iOS）
• WebAssembly性能优化
• 小程序云开发集成
