一、架构设计原理

基于蓝牙信标+路径规划算法+跨平台地图渲染的导航系统，支持iOS/Android/小程序多端运行

二、核心功能实现

1. 蓝牙信标定位引擎

// beacon-service.js
export class BeaconService {
    constructor() {
        this.beacons = new Map()
        this.currentPosition = null
    }

    startScan() {
        uni.startBeaconDiscovery({
            uuids: ['FDA50693-A4E2-4FB1-AFCF-C6EB07647825'],
            success: () => this.onBeaconUpdate(),
            fail: (err) => console.error('蓝牙扫描失败', err)
        })

        uni.onBeaconUpdate(res => {
            this.updateBeacons(res.beacons)
            this.calculatePosition()
        })
    }

    updateBeacons(beacons) {
        beacons.forEach(beacon => {
            this.beacons.set(beacon.major + '-' + beacon.minor, {
                x: beacon.major,
                y: beacon.minor,
                distance: this.calculateDistance(beacon.rssi)
            })
        })
    }

    calculatePosition() {
        // 三点定位算法实现
        const [b1, b2, b3] = [...this.beacons.values()]
        this.currentPosition = this.trilateration(b1, b2, b3)
    }
}

2. 跨平台地图渲染

import { ref, onMounted } from 'vue'
import { useBeacon } from './beacon-service'

const { currentPosition } = useBeacon()
const canvasRef = ref(null)

onMounted(() => {
    const ctx = uni.createCanvasContext('mapCanvas', this)

    // 绘制地图底图
    uni.getImageInfo({
        src: '/static/map-floor1.jpg',
        success: (res) => {
            ctx.drawImage(res.path, 0, 0, 300, 400)
            ctx.draw()
        }
    })
})

watch(currentPosition, (pos) => {
    if (pos) {
        const ctx = uni.createCanvasContext('mapCanvas', this)
        ctx.setFillStyle('#FF0000')
        ctx.arc(pos.x, pos.y, 5, 0, 2 * Math.PI)
        ctx.fill()
        ctx.draw()
    }
})





3. 路径规划服务

// path-service.js
export class PathService {
    constructor(mapData) {
        this.nodes = mapData.nodes
        this.edges = mapData.edges
    }

    findPath(start, end) {
        const openSet = [start]
        const cameFrom = new Map()
        const gScore = new Map(this.nodes.map(n => [n.id, Infinity]))
        const fScore = new Map(this.nodes.map(n => [n.id, Infinity]))

        gScore.set(start.id, 0)
        fScore.set(start.id, this.heuristic(start, end))

        while (openSet.length > 0) {
            const current = this.getLowestFScore(openSet, fScore)

            if (current.id === end.id) {
                return this.reconstructPath(cameFrom, current)
            }

            openSet.splice(openSet.indexOf(current), 1)

            this.getNeighbors(current).forEach(neighbor => {
                const tentativeGScore = gScore.get(current.id) +
                    this.distanceBetween(current, neighbor)

                if (tentativeGScore < gScore.get(neighbor.id)) {
                    cameFrom.set(neighbor.id, current)
                    gScore.set(neighbor.id, tentativeGScore)
                    fScore.set(neighbor.id,
                        tentativeGScore + this.heuristic(neighbor, end))

                    if (!openSet.includes(neighbor)) {
                        openSet.push(neighbor)
                    }
                }
            })
        }

        return null // 未找到路径
    }
}

三、高级功能实现

1. AR实景导航

// ar-navigator.js
export class ARNavigator {
    constructor() {
        this.ctx = uni.createCameraContext()
        this.markers = []
    }

    startAR(path) {
        this.markers = path.map((node, i) => ({
            id: i,
            latitude: node.lat,
            longitude: node.lng,
            iconPath: '/static/arrow.png',
            width: 20,
            height: 20
        }))

        uni.startDeviceMotionListening({
            interval: 'game',
            success: () => this.updateCamera()
        })
    }

    updateCamera() {
        uni.onDeviceMotionChange(res => {
            const angle = Math.atan2(res.beta, res.gamma) * 180 / Math.PI
            this.markers.forEach(m => {
                m.rotate = angle
            })
        })
    }
}

2. 性能优化方案

• 信标过滤：RSSI动态阈值
• 路径缓存：常用路线预计算
• 按需渲染：可视区域优化
• 节流处理：定位频率控制

四、实战案例演示

1. 完整导航流程

// pages/navigation/index.vue

import { useBeacon, usePath, useAR } from '@/services'

const { currentPosition } = useBeacon()
const { findPath } = usePath()
const { startAR } = useAR()

const startNavigation = (destination) => {
    const path = findPath(currentPosition.value, destination)
    if (path) {
        startAR(path)
    }
}




    导航至洗手间

2. 性能测试数据

测试环境：商场场景/10个信标
定位精度：2-3米
响应延迟：平均200ms
内存占用：≈80MB
兼容性：iOS12+/Android8+
