UniApp跨平台直播应用开发实战：从零构建高互动直播系统

发布日期：2024年1月17日 | 作者：移动开发专家

一、直播应用架构概述

UniApp凭借其”一次开发，多端发布”的特性，成为构建跨平台直播应用的理想选择。本文将深入讲解如何基于UniApp开发一个功能完整的直播应用，涵盖推流、拉流、实时互动等核心功能。

技术架构图：

客户端(UniApp) → 信令服务器 → 媒体服务器 → CDN网络
     ↓              ↓             ↓           ↓
    UI渲染        房间管理       流处理      内容分发
   音视频采集     用户认证       转码录制    边缘加速
   弹幕渲染       消息路由       连麦混流    全球分发

核心功能模块：

直播推流：基于live-pusher组件的实时视频采集与推送
直播观看：live-player组件的多协议流媒体播放
实时弹幕：WebSocket实现的即时消息系统
礼物系统：动画效果与实时交互的礼物功能
连麦互动：RTMP/WebRTC技术的实时音视频通话

二、开发环境搭建

1. 项目初始化

// 使用Vue3 + Vite创建项目
vue create -p dcloudio/uni-preset-vue#vite my-live-app

// 选择模板
? 请选择 uni-app 模板 (使用箭头键)
❯ 默认模板(TypeScript)
  默认模板
  自定义模板

// 安装直播相关依赖
npm install @dcloudio/uni-ui
npm install socket.io-client
npm install qiniu-js

2. 项目目录结构

src/
├── pages/
│   ├── index/
│   │   ├── index.vue          # 直播列表页
│   │   └── components/
│   ├── live-room/
│   │   ├── live-room.vue      # 直播间页
│   │   └── components/
│   └── profile/
│       └── profile.vue        # 个人中心
├── static/
│   ├── images/
│   │   ├── gifts/             # 礼物图片
│   │   └── effects/           # 特效动画
│   └── icons/
├── store/
│   ├── live.js               # 直播状态管理
│   └── user.js               # 用户状态管理
├── utils/
│   ├── socket.js             # WebSocket封装
│   ├── rtmp.js               # RTMP工具类
│   └── gift-animation.js     # 礼物动画
└── services/
    ├── live-service.js       # 直播API服务
    └── user-service.js       # 用户API服务

3. 配置文件

// manifest.json 配置
{
    "name": "LiveApp",
    "appid": "__UNI__XXXXXX",
    "description": "跨平台直播应用",
    "versionName": "1.0.0",
    "versionCode": "100",
    "transformPx": false,
    "app-plus": {
        "usingComponents": true,
        "nvueStyleCompiler": "uni-app",
        "compilerVersion": 3,
        "modules": {
            "LivePusher": {},
            "LivePlayer": {}
        },
        "distribute": {
            "android": {
                "permissions": [
                    "",
                    ""
                ]
            },
            "ios": {
                "privacies": [
                    "NSCameraUsageDescription",
                    "NSMicrophoneUsageDescription"
                ]
            }
        }
    }
}

三、直播核心功能实现

1. 直播推流功能

<template>
  <view class="live-pusher-container">
    <live-pusher
      ref="livePusher"
      :url="pushUrl"
      mode="SD"
      :muted="false"
      :enable-camera="true"
      :auto-focus="true"
      :beauty="beautyLevel"
      :whiteness="whitenessLevel"
      :aspect="'3:4'"
      @statechange="onPushStateChange"
      @netstatus="onPushNetStatus"
      class="live-pusher"
    ></live-pusher>

    <view class="control-panel">
      <button @tap="switchCamera">切换摄像头</button>
      <slider :value="beautyLevel" @change="onBeautyChange" min="0" max="9" />
      <button @tap="startPush" v-if="!isPushing">开始直播</button>
      <button @tap="stopPush" v-else>结束直播</button>
    </view>
  </view>
</template>

<script setup>
import { ref, reactive, onMounted } from 'vue'

const pushUrl = ref('')
const isPushing = ref(false)
const beautyLevel = ref(5)
const whitenessLevel = ref(5)
const livePusher = ref(null)

// 生成推流地址
const generatePushUrl = async () => {
  const roomId = await generateRoomId()
  const timestamp = Date.now()
  const token = await generatePushToken(roomId, timestamp)
  pushUrl.value = `rtmp://your-push-server.com/live/${roomId}?token=${token}&t=${timestamp}`
}

// 开始推流
const startPush = () => {
  if (!pushUrl.value) {
    uni.showToast({ title: '推流地址生成失败', icon: 'none' })
    return
  }

  livePusher.value.start()
  isPushing.value = true

  // 通知服务器直播开始
  LiveService.notifyLiveStart({
    roomId: getRoomIdFromUrl(pushUrl.value),
    title: '我的直播间',
    cover: 'default_cover.jpg'
  })
}

// 推流状态监听
const onPushStateChange = (e) => {
  console.log('推流状态:', e.detail.code, e.detail.message)
  switch(e.detail.code) {
    case 1001:
      uni.showToast({ title: '连接成功', icon: 'success' })
      break
    case 1002:
      uni.showToast({ title: '连接断开', icon: 'none' })
      isPushing.value = false
      break
    case -1301:
      uni.showToast({ title: '打开摄像头失败', icon: 'none' })
      break
  }
}

// 网络状态监听
const onPushNetStatus = (e) => {
  const { videoBitrate, audioBitrate, netSpeed } = e.detail
  console.log(`视频码率: ${videoBitrate}kbps, 音频码率: ${audioBitrate}kbps, 网速: ${netSpeed}kb/s`)
}

const switchCamera = () => {
  livePusher.value.switchCamera()
}

const onBeautyChange = (e) => {
  beautyLevel.value = e.detail.value
}

onMounted(() => {
  generatePushUrl()
})
</script>

2. 直播观看功能

<template>
  <view class="live-player-container">
    <live-player
      :src="playUrl"
      mode="live"
      autoplay
      :muted="false"
      :orientation="'vertical'"
      :object-fit="'contain'"
      @statechange="onPlayStateChange"
      @fullscreenchange="onFullscreenChange"
      class="live-player"
    ></live-player>

    <view class="player-controls">
      <button @tap="togglePlay">{{ isPlaying ? '暂停' : '播放' }}</button>
      <button @tap="toggleFullscreen">全屏</button>
      <button @tap="switchDefinition">清晰度</button>
    </view>

    <!-- 弹幕层 -->
    <danmu-layer :messages="danmuList" />
  </view>
</template>

<script setup>
import { ref, reactive, onMounted } from 'vue'

const props = defineProps({
  roomId: String
})

const playUrl = ref('')
const isPlaying = ref(true)
const danmuList = ref([])
const livePlayer = ref(null)

// 生成播放地址
const generatePlayUrl = () => {
  // 支持多种格式
  const formats = {
    rtmp: `rtmp://your-play-server.com/live/${props.roomId}`,
    flv: `https://your-cdn.com/live/${props.roomId}.flv`,
    hls: `https://your-cdn.com/live/${props.roomId}.m3u8`
  }

  // 根据平台选择最优格式
  playUrl.value = formats.hls // HLS兼容性最好
}

const togglePlay = () => {
  if (isPlaying.value) {
    livePlayer.value.pause()
  } else {
    livePlayer.value.resume()
  }
  isPlaying.value = !isPlaying.value
}

const toggleFullscreen = () => {
  livePlayer.value.requestFullScreen({ direction: 0 })
}

const onPlayStateChange = (e) => {
  console.log('播放状态:', e.detail.code)
  switch(e.detail.code) {
    case 2001:
      uni.showToast({ title: '已经连接服务器', icon: 'none' })
      break
    case 2002:
      uni.showToast({ title: '已经连接服务器,开始拉流', icon: 'none' })
      break
    case 2003:
      uni.showToast({ title: '网络接收到首个视频数据包', icon: 'none' })
      break
    case 2004:
      uni.showToast({ title: '视频播放开始', icon: 'success' })
      break
    case 2006:
      uni.showToast({ title: '视频播放进度', icon: 'none' })
      break
    case -2301:
      uni.showToast({ title: '网络断连，且经多次重连抢救无效', icon: 'none' })
      break
  }
}

onMounted(() => {
  generatePlayUrl()
  connectToRoom() // 连接直播间WebSocket
})
</script>

四、互动功能开发

1. 实时弹幕系统

// utils/socket.js - WebSocket封装
class LiveSocket {
  constructor() {
    this.socket = null
    this.reconnectCount = 0
    this.maxReconnect = 5
    this.listeners = new Map()
  }

  connect(roomId, token) {
    return new Promise((resolve, reject) => {
      this.socket = uni.connectSocket({
        url: `wss://your-websocket-server.com/ws?roomId=${roomId}&token=${token}`,
        success: () => {
          console.log('WebSocket连接成功')
          this.setupEventListeners()
          resolve()
        },
        fail: (err) => {
          console.error('WebSocket连接失败:', err)
          reject(err)
        }
      })
    })
  }

  setupEventListeners() {
    // 监听连接打开
    this.socket.onOpen(() => {
      console.log('WebSocket已连接')
      this.reconnectCount = 0
    })

    // 监听消息接收
    this.socket.onMessage((res) => {
      const data = JSON.parse(res.data)
      this.emit(data.type, data.payload)
    })

    // 监听连接关闭
    this.socket.onClose(() => {
      console.log('WebSocket连接关闭')
      this.handleReconnect()
    })

    // 监听错误
    this.socket.onError((err) => {
      console.error('WebSocket错误:', err)
    })
  }

  // 发送消息
  send(type, payload) {
    if (this.socket && this.socket.readyState === 1) {
      this.socket.send({
        data: JSON.stringify({ type, payload })
      })
    }
  }

  // 监听消息
  on(type, callback) {
    if (!this.listeners.has(type)) {
      this.listeners.set(type, [])
    }
    this.listeners.get(type).push(callback)
  }

  // 触发消息
  emit(type, data) {
    const callbacks = this.listeners.get(type)
    if (callbacks) {
      callbacks.forEach(callback => callback(data))
    }
  }

  // 重连机制
  handleReconnect() {
    if (this.reconnectCount  {
        this.connect()
      }, 1000 * this.reconnectCount)
    }
  }
}

export default new LiveSocket()

2. 弹幕组件实现

<template>
  <view class="danmu-layer">
    <view
      v-for="(item, index) in visibleMessages"
      :key="item.id"
      :class="['danmu-item', `danmu-${item.type}`]"
      :style="getDanmuStyle(item, index)"
    >
      <image v-if="item.avatar" :src="item.avatar" class="avatar" />
      <text class="username">{{ item.username }}：</text>
      <text class="content">{{ item.content }}</text>
    </view>
  </view>
</template>

<script setup>
import { ref, reactive, onMounted, onUnmounted } from 'vue'

const props = defineProps({
  messages: Array
})

const visibleMessages = ref([])
const messagePool = ref([])

// 添加弹幕
const addDanmu = (message) => {
  message.id = Date.now() + Math.random()
  message.top = Math.random() * 70 + 10 // 随机顶部位置
  message.speed = Math.random() * 2 + 1 // 随机速度

  messagePool.value.push(message)

  // 限制弹幕数量
  if (messagePool.value.length > 50) {
    messagePool.value.shift()
  }

  updateVisibleMessages()
}

// 更新可见弹幕
const updateVisibleMessages = () => {
  visibleMessages.value = [...messagePool.value]
}

// 获取弹幕样式
const getDanmuStyle = (item, index) => {
  return {
    top: `${item.top}%`,
    animationDuration: `${item.speed}s`,
    zIndex: 1000 + index
  }
}

// 监听弹幕消息
onMounted(() => {
  LiveSocket.on('danmu', (data) => {
    addDanmu(data)
  })

  LiveSocket.on('gift', (data) => {
    addDanmu({
      ...data,
      type: 'gift',
      content: `送出了${data.giftName}`
    })
  })
})

onUnmounted(() => {
  LiveSocket.off('danmu')
  LiveSocket.off('gift')
})
</script>

3. 礼物系统与动画

// utils/gift-animation.js
class GiftAnimation {
  constructor() {
    this.animations = new Map()
    this.initAnimations()
  }

  initAnimations() {
    // 初始化礼物动画配置
    this.animations.set('rose', {
      duration: 3000,
      effect: 'fadeInOut',
      sound: 'gift_rose.mp3'
    })

    this.animations.set('rocket', {
      duration: 5000,
      effect: 'flyToMoon',
      sound: 'gift_rocket.mp3'
    })
  }

  // 播放礼物动画
  play(giftType, options = {}) {
    const config = this.animations.get(giftType)
    if (!config) {
      console.warn(`未找到礼物类型: ${giftType}的动画配置`)
      return
    }

    this.createAnimationElement(giftType, config, options)
  }

  createAnimationElement(giftType, config, options) {
    const animationId = `gift-${Date.now()}`
    const animationNode = {
      id: animationId,
      type: giftType,
      username: options.username,
      giftName: options.giftName,
      config: config
    }

    // 发送动画消息到页面
    uni.$emit('giftAnimation', animationNode)

    // 自动清理
    setTimeout(() => {
      uni.$emit('removeGiftAnimation', animationId)
    }, config.duration)
  }
}

export default new GiftAnimation()

五、性能优化与部署

1. 性能优化策略

// 直播流质量自适应
const adaptStreamQuality = (netStatus) => {
  const { netSpeed, videoBitrate } = netStatus

  if (netSpeed  2000) {
    // 网络良好，切换为高清
    switchToHighQuality()
  } else {
    // 网络一般，保持标清
    switchToStandardQuality()
  }
}

// 内存优化 - 清理历史消息
const cleanupMessageHistory = () => {
  if (messagePool.value.length > 100) {
    messagePool.value = messagePool.value.slice(-50)
  }
}

// 图片懒加载优化
const lazyLoadImages = () => {
  const images = document.querySelectorAll('img[data-src]')
  const observer = new IntersectionObserver((entries) => {
    entries.forEach(entry => {
      if (entry.isIntersecting) {
        const img = entry.target
        img.src = img.dataset.src
        observer.unobserve(img)
      }
    })
  })

  images.forEach(img => observer.observe(img))
}

2. 多平台适配

// 平台特定功能处理
const handlePlatformSpecific = () => {
  // #ifdef APP-PLUS
  setupAppSpecificFeatures()
  // #endif

  // #ifdef H5
  setupH5SpecificFeatures()
  // #endif

  // #ifdef MP-WEIXIN
  setupWechatSpecificFeatures()
  // #endif
}

// 微信小程序特定配置
const setupWechatSpecificFeatures = () => {
  // 微信小程序直播组件特殊处理
  const livePlayerContext = uni.createLivePlayerContext('livePlayer')
  const livePusherContext = uni.createLivePusherContext('livePusher')

  // 微信小程序权限处理
  uni.authorize({
    scope: 'scope.camera',
    success: () => {
      console.log('摄像头权限已授权')
    },
    fail: () => {
      uni.showModal({
        title: '权限申请',
        content: '需要摄像头权限才能进行直播',
        success: (res) => {
          if (res.confirm) {
            uni.openSetting()
          }
        }
      })
    }
  })
}

3. 发布部署配置

// package.json 构建脚本
{
  "scripts": {
    "build:app": "uni-build --app",
    "build:h5": "uni-build --h5",
    "build:mp-weixin": "uni-build --mp-weixin",
    "build:all": "npm run build:app && npm run build:h5 && npm run build:mp-weixin"
  }
}

// GitHub Actions 自动化部署
// .github/workflows/deploy.yml
name: Deploy Live App
on:
  push:
    branches: [ main ]

jobs:
  build-and-deploy:
    runs-on: ubuntu-latest
    steps:
    - uses: actions/checkout@v2
    - name: Setup Node.js
      uses: actions/setup-node@v2
      with:
        node-version: '16'
    - name: Install dependencies
      run: npm install
    - name: Build for all platforms
      run: npm run build:all
    - name: Deploy to CDN
      uses: easingthemes/ssh-deploy@v2
      env:
        SSH_PRIVATE_KEY: ${{ secrets.SSH_PRIVATE_KEY }}
        SOURCE: "dist/"
        REMOTE_HOST: ${{ secrets.REMOTE_HOST }}
        REMOTE_USER: ${{ secrets.REMOTE_USER }}
        TARGET: ${{ secrets.REMOTE_TARGET }}
