JavaScript大型前端项目架构实战 | 工程化与性能优化全解析

一、现代化前端架构设计

本教程将基于JavaScript构建一个企业级前端应用，涵盖从项目初始化到生产部署的完整工程化流程。

技术架构：

核心框架：Vue 3.2 + Composition API
构建工具：Webpack 5 + Vite 3
状态管理：Pinia 2.0
UI组件：Element Plus + 自定义主题
代码规范：ESLint + Prettier + Husky

核心功能模块：

微前端架构实现
自动化代码分割
可视化性能监控
静态资源优化方案
CI/CD流水线配置

二、项目初始化与工程配置

1. 多模式项目创建

# 使用Vite创建基础项目
npm create vite@latest enterprise-app --template vue-ts

# 添加核心依赖
cd enterprise-app
npm install pinia vue-router@4 element-plus
npm install @vueuse/core lodash-es

# 添加开发依赖
npm install eslint prettier eslint-plugin-vue @typescript-eslint/parser -D

2. 目录结构设计

src/
├── apis/               # API模块化
├── assets/             # 静态资源
│   ├── fonts/          # 字体文件
│   └── styles/         # 全局样式
├── components/         # 公共组件
│   ├── business/       # 业务组件
│   └── ui/            # 基础UI组件
├── composables/        # 组合式函数
├── layouts/            # 布局组件
├── router/             # 路由配置
├── stores/             # Pinia状态
├── utils/              # 工具函数
├── views/              # 页面组件
├── App.vue             # 根组件
└── main.ts             # 应用入口

三、核心架构实现

1. 自动化按需加载

// router/index.ts
import { createRouter, createWebHistory } from 'vue-router'

const routes = [
  {
    path: '/',
    name: 'Home',
    component: () => import('@/views/Home.vue'),
    meta: {
      preload: true // 标记需要预加载的路由
    }
  },
  {
    path: '/about',
    name: 'About',
    component: () => import('@/views/About.vue')
  }
]

const router = createRouter({
  history: createWebHistory(),
  routes
})

// 路由预加载逻辑
router.beforeEach((to, from, next) => {
  if (to.matched.some(record => record.meta.preload)) {
    const matchedComponents = to.matched.map(record => record.components.default)
    Promise.all(matchedComponents.map(component => {
      if (typeof component === 'function') {
        return component()
      }
      return Promise.resolve()
    }))
  }
  next()
})

export default router

2. 状态管理设计

// stores/userStore.ts
import { defineStore } from 'pinia'
import { ref, computed } from 'vue'
import { fetchUserInfo, login } from '@/apis/user'

export const useUserStore = defineStore('user', () => {
  const userInfo = ref(null)
  const token = ref(localStorage.getItem('token') || '')

  const isLogin = computed(() => !!token.value)

  async function loginAction(credentials) {
    try {
      const res = await login(credentials)
      token.value = res.token
      localStorage.setItem('token', res.token)
      await getUserInfo()
    } catch (error) {
      throw error
    }
  }

  async function getUserInfo() {
    if (!token.value) return
    userInfo.value = await fetchUserInfo()
  }

  function logout() {
    token.value = ''
    userInfo.value = null
    localStorage.removeItem('token')
  }

  return {
    userInfo,
    token,
    isLogin,
    loginAction,
    getUserInfo,
    logout
  }
})

四、性能优化实践

1. 虚拟列表实现

<template>
  <div class="virtual-list" ref="listContainer">
    <div class="list-phantom" :style="{ height: totalHeight + 'px' }"></div>
    <div
      class="list-content"
      :style="{ transform: `translateY(${offset}px)` }">
      <div
        v-for="item in visibleData"
        :key="item.id"
        class="list-item"
        :style="{ height: itemHeight + 'px' }">
        {{ item.content }}
      </div>
    </div>
  </div>
</template>

<script setup lang="ts">
import { ref, computed, onMounted, onUnmounted } from 'vue'

const props = defineProps({
  data: {
    type: Array,
    required: true
  },
  itemHeight: {
    type: Number,
    default: 60
  }
})

const listContainer = ref(null)
const offset = ref(0)
const startIndex = ref(0)
const visibleCount = ref(0)

const totalHeight = computed(() => {
  return props.data.length * props.itemHeight
})

const endIndex = computed(() => {
  return Math.min(startIndex.value + visibleCount.value, props.data.length)
})

const visibleData = computed(() => {
  return props.data.slice(startIndex.value, endIndex.value)
})

function updateVisibleData() {
  if (!listContainer.value) return
  const scrollTop = listContainer.value.scrollTop
  startIndex.value = Math.floor(scrollTop / props.itemHeight)
  offset.value = scrollTop - (scrollTop % props.itemHeight)
}

onMounted(() => {
  visibleCount.value = Math.ceil(listContainer.value.clientHeight / props.itemHeight)
  listContainer.value.addEventListener('scroll', updateVisibleData)
})

onUnmounted(() => {
  listContainer.value.removeEventListener('scroll', updateVisibleData)
})
</script>

2. Webpack深度优化

// vite.config.ts
import { defineConfig } from 'vite'
import vue from '@vitejs/plugin-vue'
import { visualizer } from 'rollup-plugin-visualizer'

export default defineConfig({
  plugins: [
    vue(),
    visualizer({
      open: true,
      gzipSize: true,
      brotliSize: true
    })
  ],
  build: {
    rollupOptions: {
      output: {
        manualChunks(id) {
          if (id.includes('node_modules')) {
            if (id.includes('lodash')) {
              return 'lodash'
            }
            if (id.includes('element-plus')) {
              return 'element-plus'
            }
            return 'vendor'
          }
        }
      }
    },
    chunkSizeWarningLimit: 1000
  }
})

五、微前端架构实现

1. 基于Module Federation的微前端

// webpack.config.js (主应用)
const ModuleFederationPlugin = require('webpack/lib/container/ModuleFederationPlugin')

module.exports = {
  plugins: [
    new ModuleFederationPlugin({
      name: 'host',
      remotes: {
        app1: 'app1@http://localhost:3001/remoteEntry.js',
        app2: 'app2@http://localhost:3002/remoteEntry.js'
      },
      shared: {
        vue: { singleton: true },
        'vue-router': { singleton: true },
        pinia: { singleton: true }
      }
    })
  ]
}

// webpack.config.js (子应用)
module.exports = {
  plugins: [
    new ModuleFederationPlugin({
      name: 'app1',
      filename: 'remoteEntry.js',
      exposes: {
        './App': './src/bootstrap.js'
      },
      shared: {
        vue: { singleton: true },
        'vue-router': { singleton: true },
        pinia: { singleton: true }
      }
    })
  ]
}

2. 动态加载微应用

// src/utils/loadMicroApp.js
export function loadMicroApp(scope, module) {
  return new Promise((resolve, reject) => {
    const element = document.createElement('script')

    element.src = `${scope.url}/remoteEntry.js`
    element.type = 'text/javascript'
    element.async = true

    element.onload = () => {
      const proxy = {
        get: (request) => window[scope.name].get(request),
        init: (arg) => {
          try {
            return window[scope.name].init(arg)
          } catch (e) {
            reject(e)
          }
        }
      }

      proxy.init(scope.sharedScope || {})
        .then(() => proxy.get(module))
        .then(factory => {
          const Module = factory()
          resolve(Module)
        })
        .catch(reject)
    }

    element.onerror = reject
    document.head.appendChild(element)
  })
}

// 使用示例
loadMicroApp(
  { name: 'app1', url: 'http://localhost:3001' },
  './App'
).then(module => {
  // 渲染微应用
})

六、监控与异常处理

1. 前端监控系统

// src/utils/monitor.js
class FrontendMonitor {
  constructor(options) {
    this.options = options
    this.initPerformanceObserver()
    this.initErrorHandler()
  }

  initPerformanceObserver() {
    if ('PerformanceObserver' in window) {
      const observer = new PerformanceObserver((list) => {
        const entries = list.getEntries()
        entries.forEach(entry => {
          if (entry.entryType === 'longtask') {
            this.report('longtask', {
              duration: entry.duration,
              startTime: entry.startTime
            })
          }
        })
      })
      observer.observe({ entryTypes: ['longtask'] })
    }
  }

  initErrorHandler() {
    window.addEventListener('error', (event) => {
      this.report('error', {
        message: event.message,
        filename: event.filename,
        lineno: event.lineno,
        colno: event.colno,
        stack: event.error?.stack
      })
    })

    window.addEventListener('unhandledrejection', (event) => {
      this.report('promise_error', {
        reason: event.reason?.toString(),
        stack: event.reason?.stack
      })
    })
  }

  report(type, data) {
    const reportData = {
      app: this.options.appName,
      env: this.options.env,
      type,
      data,
      timestamp: Date.now(),
      url: window.location.href,
      userAgent: navigator.userAgent
    }

    // 使用navigator.sendBeacon上报
    navigator.sendBeacon(this.options.reportUrl, JSON.stringify(reportData))
  }
}

// 初始化监控
const monitor = new FrontendMonitor({
  appName: 'enterprise-app',
  env: process.env.NODE_ENV,
  reportUrl: 'https://monitor.example.com/api/report'
})

七、自动化部署

1. CI/CD配置

# .github/workflows/deploy.yml
name: CI/CD Pipeline

on:
  push:
    branches: [ main ]
  pull_request:
    branches: [ main ]

jobs:
  build:
    runs-on: ubuntu-latest

    steps:
    - uses: actions/checkout@v2

    - name: Setup Node
      uses: actions/setup-node@v2
      with:
        node-version: '16'

    - name: Install dependencies
      run: npm ci

    - name: Run tests
      run: npm test

    - name: Build production
      run: npm run build

    - name: Upload artifacts
      uses: actions/upload-artifact@v2
      with:
        name: dist
        path: dist

  deploy:
    needs: build
    runs-on: ubuntu-latest

    steps:
    - name: Download artifact
      uses: actions/download-artifact@v2
      with:
        name: dist

    - name: Deploy to S3
      uses: jakejarvis/s3-sync-action@master
      with:
        args: --acl public-read --follow-symlinks --delete
      env:
        AWS_S3_BUCKET: ${{ secrets.AWS_S3_BUCKET }}
        AWS_ACCESS_KEY_ID: ${{ secrets.AWS_ACCESS_KEY_ID }}
        AWS_SECRET_ACCESS_KEY: ${{ secrets.AWS_SECRET_ACCESS_KEY }}
        AWS_REGION: 'us-east-1'
        SOURCE_DIR: 'dist'
