HTML5高级Canvas动画引擎开发实战：粒子系统与物理效果深度解析 | 网页动画编程指南

一、现代Web动画技术选型

实现高性能网页动画的三大技术路径对比：

本文将聚焦Canvas技术，实现可复用的动画引擎架构。

二、动画引擎核心架构

1. 引擎类结构设计

class AnimationEngine {
    constructor(canvas, options = {}) {
        this.canvas = canvas;
        this.ctx = canvas.getContext('2d');
        this.width = canvas.width;
        this.height = canvas.height;
        this.particles = [];
        this.forces = [];
        this.running = false;
        this.lastTime = 0;
        this.fps = options.fps || 60;
        this.frameInterval = 1000 / this.fps;
    }

    addParticle(particle) {
        this.particles.push(particle);
    }

    addForce(force) {
        this.forces.push(force);
    }

    start() {
        this.running = true;
        this.lastTime = performance.now();
        this._animate();
    }

    stop() {
        this.running = false;
    }

    _animate() {
        if (!this.running) return;

        const now = performance.now();
        const deltaTime = now - this.lastTime;

        if (deltaTime > this.frameInterval) {
            this._update(deltaTime);
            this._render();
            this.lastTime = now - (deltaTime % this.frameInterval);
        }

        requestAnimationFrame(() => this._animate());
    }

    _update(deltaTime) {
        // 物理模拟和粒子状态更新
        this._applyForces();
        this._updateParticles(deltaTime);
        this._handleCollisions();
    }

    _render() {
        // 清空画布
        this.ctx.clearRect(0, 0, this.width, this.height);

        // 渲染所有粒子
        this.particles.forEach(particle => {
            particle.render(this.ctx);
        });
    }
}

2. 粒子系统实现

class Particle {
    constructor(x, y, radius, color) {
        this.x = x;
        this.y = y;
        this.radius = radius;
        this.color = color;
        this.velocity = { x: 0, y: 0 };
        this.acceleration = { x: 0, y: 0 };
        this.mass = radius * radius;
        this.life = 1000; // 粒子生命周期(ms)
    }

    update(deltaTime) {
        // 更新速度
        this.velocity.x += this.acceleration.x;
        this.velocity.y += this.acceleration.y;

        // 更新位置
        this.x += this.velocity.x * deltaTime / 1000;
        this.y += this.velocity.y * deltaTime / 1000;

        // 重置加速度
        this.acceleration = { x: 0, y: 0 };

        // 更新生命周期
        this.life -= deltaTime;
    }

    applyForce(force) {
        this.acceleration.x += force.x / this.mass;
        this.acceleration.y += force.y / this.mass;
    }

    render(ctx) {
        ctx.beginPath();
        ctx.arc(this.x, this.y, this.radius, 0, Math.PI * 2);
        ctx.fillStyle = this.color;
        ctx.fill();
        ctx.closePath();
    }
}

三、物理效果实现

1. 力场模拟

// 重力场
class Gravity {
    constructor(force = 9.8) {
        this.force = force;
        this.direction = { x: 0, y: 1 };
    }

    applyTo(particle) {
        particle.applyForce({
            x: this.direction.x * this.force * particle.mass,
            y: this.direction.y * this.force * particle.mass
        });
    }
}

// 风力场
class Wind {
    constructor(force, direction) {
        this.force = force;
        this.direction = direction || {
            x: Math.random() * 2 - 1,
            y: Math.random() - 0.5
        };
    }

    applyTo(particle) {
        particle.applyForce({
            x: this.direction.x * this.force,
            y: this.direction.y * this.force
        });
    }
}

2. 碰撞检测优化

class CollisionSystem {
    constructor(engine) {
        this.engine = engine;
        this.gridSize = 50; // 网格大小
        this.grid = {};
    }

    _hashPosition(x, y) {
        return `${Math.floor(x/this.gridSize)}_${Math.floor(y/this.gridSize)}`;
    }

    _buildGrid() {
        this.grid = {};
        this.engine.particles.forEach(particle => {
            const hash = this._hashPosition(particle.x, particle.y);
            if (!this.grid[hash]) this.grid[hash] = [];
            this.grid[hash].push(particle);
        });
    }

    checkCollisions() {
        this._buildGrid();

        Object.values(this.grid).forEach(cell => {
            if (cell.length < 2) return;

            // 检查同一网格内的粒子碰撞
            for (let i = 0; i < cell.length; i++) {
                for (let j = i + 1; j < cell.length; j++) {
                    this._checkPair(cell[i], cell[j]);
                }
            }
        });
    }

    _checkPair(p1, p2) {
        const dx = p1.x - p2.x;
        const dy = p1.y - p2.y;
        const distance = Math.sqrt(dx * dx + dy * dy);

        if (distance < p1.radius + p2.radius) {
            this._resolveCollision(p1, p2, dx/distance, dy/distance);
        }
    }
}

四、特效系统开发

1. 粒子发射器

class ParticleEmitter {
    constructor(x, y) {
        this.x = x;
        this.y = y;
        this.particlesPerSecond = 30;
        this.lastEmitTime = 0;
        this.particleConfig = {
            radius: () => Math.random() * 3 + 1,
            color: () => `hsl(${Math.random()*60+10}, 100%, 50%)`,
            velocity: () => ({
                x: (Math.random() - 0.5) * 100,
                y: (Math.random() - 0.5) * 100
            })
        };
    }

    update(engine, time) {
        const shouldEmit = time - this.lastEmitTime > 1000/this.particlesPerSecond;
        if (!shouldEmit) return;

        this.lastEmitTime = time;

        const particle = new Particle(
            this.x,
            this.y,
            this.particleConfig.radius(),
            this.particleConfig.color()
        );

        const velocity = this.particleConfig.velocity();
        particle.velocity = velocity;

        engine.addParticle(particle);
    }
}

2. 高级渲染效果

// 粒子轨迹效果
Particle.prototype.render = function(ctx) {
    // 创建径向渐变
    const gradient = ctx.createRadialGradient(
        this.x, this.y, 0,
        this.x, this.y, this.radius
    );
    gradient.addColorStop(0, this.color);
    gradient.addColorStop(1, 'transparent');

    // 绘制发光效果
    ctx.beginPath();
    ctx.arc(this.x, this.y, this.radius * 1.5, 0, Math.PI * 2);
    ctx.fillStyle = gradient;
    ctx.globalCompositeOperation = 'lighter';
    ctx.fill();
    ctx.closePath();

    // 恢复混合模式
    ctx.globalCompositeOperation = 'source-over';
};

// 图像粒子效果
class ImageParticle extends Particle {
    constructor(x, y, image) {
        super(x, y, image.width/2, null);
        this.image = image;
        this.rotation = 0;
        this.alpha = 1;
    }

    render(ctx) {
        ctx.save();
        ctx.translate(this.x, this.y);
        ctx.rotate(this.rotation);
        ctx.globalAlpha = this.alpha;
        ctx.drawImage(
            this.image,
            -this.radius,
            -this.radius,
            this.radius * 2,
            this.radius * 2
        );
        ctx.restore();
    }
}

五、性能优化实战

1. 离屏Canvas技术

class ParticleCache {
    constructor(particle) {
        this.offscreenCanvas = document.createElement('canvas');
        this.offscreenCanvas.width = particle.radius * 4;
        this.offscreenCanvas.height = particle.radius * 4;

        const ctx = this.offscreenCanvas.getContext('2d');
        particle.render(ctx);
    }

    render(ctx, x, y) {
        ctx.drawImage(
            this.offscreenCanvas,
            x - this.offscreenCanvas.width/2,
            y - this.offscreenCanvas.height/2
        );
    }
}

// 使用缓存渲染
const cache = new ParticleCache(new Particle(0, 0, 10, 'red'));
particles.forEach(particle => {
    cache.render(ctx, particle.x, particle.y);
});

2. Web Workers并行计算

// worker.js
self.onmessage = function(e) {
    const { particles, forces, deltaTime } = e.data;

    // 在Worker中计算物理模拟
    const updatedParticles = particles.map(particle => {
        const p = {...particle};

        forces.forEach(force => {
            if (force.type === 'gravity') {
                p.velocity.y += 9.8 * deltaTime / 1000;
            }
            // 其他力场计算...
        });

        p.x += p.velocity.x * deltaTime / 1000;
        p.y += p.velocity.y * deltaTime / 1000;

        return p;
    });

    self.postMessage(updatedParticles);
};

// 主线程
const worker = new Worker('worker.js');
worker.onmessage = function(e) {
    this.particles = e.data;
};

// 每帧发送数据到Worker
worker.postMessage({
    particles: this.particles,
    forces: this.forces,
    deltaTime: deltaTime
});
