PHP高性能实时股票行情系统开发实战：从数据采集到WebSocket推送 | 金融科技解决方案

一、金融行情系统技术选型

主流实时数据处理方案对比：

二、系统架构设计

1. 分布式架构设计

数据源 → 采集集群 → 处理中心 → 分发节点 → 客户端
    ↑           ↑            ↑           ↑
交易所API   多协议适配    实时计算引擎   WebSocket网关


2. 数据流转流程

行情采集 → 协议解析 → 数据清洗 → 业务处理 → 压缩传输 → 客户端渲染
    ↑           ↑           ↑           ↑           ↑           ↑
TCP/UDP     二进制解码    异常值过滤    涨跌计算     Snappy压缩    Canvas绘图

三、核心模块实现

1. 高性能行情采集服务

<?php
class MarketDataCollector
{
    private $sources = [];
    private $buffer = [];
    private $isRunning = false;

    public function addSource(string $source, callable $parser)
    {
        $this->sources[$source] = $parser;
    }

    public function start()
    {
        $this->isRunning = true;

        // 启动多个协程并发采集
        foreach ($this->sources as $source => $parser) {
            go(function() use ($source, $parser) {
                $client = new SwooleCoroutineHttpClient(
                    parse_url($source, PHP_URL_HOST),
                    parse_url($source, PHP_URL_PORT) ?? 80
                );

                while ($this->isRunning) {
                    $client->get(parse_url($source, PHP_URL_PATH));

                    if ($client->statusCode === 200) {
                        $data = $parser($client->body);
                        $this->bufferData($data);
                    }

                    Coroutine::sleep(0.1); // 100ms间隔
                }
            });
        }
    }

    private function bufferData(array $data)
    {
        foreach ($data as $symbol => $tick) {
            $this->buffer[$symbol][] = $tick;

            // 缓冲控制
            if (count($this->buffer[$symbol]) > 100) {
                array_shift($this->buffer[$symbol]);
            }
        }
    }

    public function getLatest(): array
    {
        $snapshot = [];
        foreach ($this->buffer as $symbol => $ticks) {
            $snapshot[$symbol] = end($ticks);
        }
        return $snapshot;
    }
}

2. WebSocket推送服务

<?php
class WebSocketServer
{
    private $server;
    private $subscribers = [];

    public function __construct(string $host, int $port)
    {
        $this->server = new SwooleWebSocketServer($host, $port);

        $this->server->on('open', function($server, $request) {
            $this->log("客户端 {$request->fd} 连接");
        });

        $this->server->on('message', function($server, $frame) {
            $this->handleMessage($frame->fd, $frame->data);
        });

        $this->server->on('close', function($server, $fd) {
            $this->unsubscribeAll($fd);
            $this->log("客户端 {$fd} 断开");
        });
    }

    private function handleMessage(int $fd, string $message)
    {
        $data = json_decode($message, true);

        switch ($data['action'] ?? '') {
            case 'subscribe':
                $this->subscribe($fd, $data['symbols']);
                break;
            case 'unsubscribe':
                $this->unsubscribe($fd, $data['symbols']);
                break;
        }
    }

    public function subscribe(int $fd, array $symbols)
    {
        foreach ($symbols as $symbol) {
            $this->subscribers[$symbol][$fd] = $fd;
        }
    }

    public function broadcast(array $data)
    {
        foreach ($data as $symbol => $tick) {
            if (empty($this->subscribers[$symbol])) {
                continue;
            }

            $payload = json_encode([
                'symbol' => $symbol,
                'data' => $tick,
                'timestamp' => time()
            ]);

            foreach ($this->subscribers[$symbol] as $fd) {
                $this->server->push($fd, $payload);
            }
        }
    }

    public function start()
    {
        $this->server->start();
    }
}

四、高级功能实现

1. K线合成引擎

<?php
class KLineGenerator
{
    private $intervals = ['1m', '5m', '15m', '1h', '4h', '1d'];
    private $buffers = [];

    public function __construct()
    {
        foreach ($this->intervals as $interval) {
            $this->buffers[$interval] = [];
        }
    }

    public function processTick(string $symbol, array $tick)
    {
        foreach ($this->intervals as $interval) {
            $period = $this->getPeriodSeconds($interval);
            $timestamp = floor($tick['timestamp'] / $period) * $period;

            if (!isset($this->buffers[$interval][$symbol][$timestamp])) {
                $this->initializeCandle($interval, $symbol, $timestamp, $tick);
            } else {
                $this->updateCandle($interval, $symbol, $timestamp, $tick);
            }

            // 检查是否完成当前K线
            if (time() - $timestamp >= $period) {
                $this->finalizeCandle($interval, $symbol, $timestamp);
            }
        }
    }

    private function initializeCandle($interval, $symbol, $timestamp, $tick)
    {
        $this->buffers[$interval][$symbol][$timestamp] = [
            'open' => $tick['price'],
            'high' => $tick['price'],
            'low' => $tick['price'],
            'close' => $tick['price'],
            'volume' => $tick['volume'],
            'start_time' => $timestamp,
            'end_time' => $timestamp + $this->getPeriodSeconds($interval)
        ];
    }

    public function getKLines($symbol, $interval, $limit = 100): array
    {
        return array_slice(
            array_reverse($this->buffers[$interval][$symbol] ?? []),
            0, $limit
        );
    }
}

2. 实时风险监控

<?php
class RiskMonitor
{
    private $alertRules = [
        'price_change' => [
            'threshold' => 0.1, // 10%
            'period' => 300 // 5分钟
        ],
        'volume_spike' => [
            'threshold' => 3.0, // 3倍平均
            'period' => 3600 // 1小时
        ]
    ];

    private $history = [];

    public function checkRisk(string $symbol, array $tick): ?array
    {
        $alerts = [];
        $this->storeHistory($symbol, $tick);

        // 价格波动检查
        $priceChange = $this->calcPriceChange($symbol, $this->alertRules['price_change']['period']);
        if (abs($priceChange) >= $this->alertRules['price_change']['threshold']) {
            $alerts[] = [
                'type' => 'price_change',
                'symbol' => $symbol,
                'value' => $priceChange,
                'threshold' => $this->alertRules['price_change']['threshold']
            ];
        }

        // 成交量突增检查
        $volumeRatio = $this->calcVolumeRatio($symbol, $this->alertRules['volume_spike']['period']);
        if ($volumeRatio >= $this->alertRules['volume_spike']['threshold']) {
            $alerts[] = [
                'type' => 'volume_spike',
                'symbol' => $symbol,
                'value' => $volumeRatio,
                'threshold' => $this->alertRules['volume_spike']['threshold']
            ];
        }

        return empty($alerts) ? null : $alerts;
    }

    private function storeHistory(string $symbol, array $tick)
    {
        $this->history[$symbol][] = $tick;

        // 保留最近24小时数据
        $cutoff = time() - 86400;
        $this->history[$symbol] = array_filter(
            $this->history[$symbol],
            fn($item) => $item['timestamp'] > $cutoff
        );
    }
}

五、性能优化策略

1. 内存优化技巧

<?php
class MemoryOptimizedStorage
{
    private $data = [];
    private $serialized = [];

    public function store(string $key, array $value)
    {
        // 使用序列化减少内存占用
        $this->serialized[$key] = igbinary_serialize($value);
        unset($this->data[$key]);
    }

    public function retrieve(string $key): array
    {
        if (!isset($this->data[$key]) && isset($this->serialized[$key])) {
            $this->data[$key] = igbinary_unserialize($this->serialized[$key]);
        }
        return $this->data[$key] ?? [];
    }

    public function optimizeMemory()
    {
        // 定期清理已加载的数据
        foreach ($this->data as $key => $value) {
            if (!isset($this->serialized[$key])) {
                $this->serialized[$key] = igbinary_serialize($value);
            }
            unset($this->data[$key]);
        }
    }
}

// 使用共享内存加速
class SharedMemoryCache
{
    private $shmId;

    public function __construct(string $key, int $size)
    {
        $this->shmId = shmop_open(
            ftok(__FILE__, $key),
            "c",
            0644,
            $size
        );
    }

    public function store(string $key, string $value)
    {
        $data = $this->loadAll();
        $data[$key] = $value;
        shmop_write($this->shmId, json_encode($data), 0);
    }

    public function loadAll(): array
    {
        $data = shmop_read($this->shmId, 0, shmop_size($this->shmId));
        return json_decode($data, true) ?: [];
    }
}

2. 协程并发控制

<?php
class CoroutinePool
{
    private $maxWorkers;
    private $channel;
    private $running = 0;

    public function __construct(int $maxWorkers)
    {
        $this->maxWorkers = $maxWorkers;
        $this->channel = new SwooleCoroutineChannel($maxWorkers);
    }

    public function submit(callable $task, ...$args): void
    {
        go(function() use ($task, $args) {
            $this->channel->push(true); // 占用一个工作槽

            try {
                $this->running++;
                $task(...$args);
            } finally {
                $this->running--;
                $this->channel->pop(); // 释放工作槽
            }
        });
    }

    public function wait(): void
    {
        while ($this->running > 0) {
            SwooleCoroutine::sleep(0.1);
        }
    }
}

// 使用示例
$pool = new CoroutinePool(200); // 最大200并发

foreach ($symbols as $symbol) {
    $pool->submit(function() use ($symbol) {
        $data = $this->marketData->getHistory($symbol);
        $this->processSymbol($symbol, $data);
    });
}

$pool->wait();

六、实战案例：券商行情系统

1. 行情数据API

<?php
class MarketDataController
{
    public function getRealtime(Request $request)
    {
        $symbols = explode(',', $request->get('symbols'));
        $data = $this->marketService->getLatest($symbols);

        return new JsonResponse([
            'code' => 200,
            'data' => $data,
            'timestamp' => time()
        ]);
    }

    public function getKLine(Request $request)
    {
        $symbol = $request->get('symbol');
        $interval = $request->get('interval', '1m');
        $limit = min($request->get('limit', 100), 1000);

        $klines = $this->klineService->getKLines($symbol, $interval, $limit);

        return new JsonResponse([
            'code' => 200,
            'data' => array_values($klines),
            'symbol' => $symbol,
            'interval' => $interval
        ]);
    }
}

2. WebSocket客户端集成

<?php
class WebSocketClient
{
    private $client;
    private $callbacks = [];

    public function __construct(string $url)
    {
        $this->client = new WebSocketClient($url);
        $this->client->onMessage(function($message) {
            $data = json_decode($message, true);
            $this->dispatch($data['event'], $data['data']);
        });
    }

    public function subscribe(array $symbols)
    {
        $this->client->send(json_encode([
            'action' => 'subscribe',
            'symbols' => $symbols
        ]));
    }

    public function on(string $event, callable $callback)
    {
        $this->callbacks[$event][] = $callback;
    }

    private function dispatch(string $event, $data)
    {
        foreach ($this->callbacks[$event] ?? [] as $callback) {
            $callback($data);
        }
    }
}

// 前端使用示例
const ws = new WebSocketClient('ws://market.example.com:9501');

ws.subscribe(['AAPL', 'MSFT', 'GOOGL']);

ws.on('price_update', function(data) {
    console.log(`股票 ${data.symbol} 最新价: ${data.price}`);
    updateChart(data);
});
