PHP高性能API网关开发实战：微服务架构下的统一入口设计

构建微服务架构下的统一入口与流量管控系统

一、API网关核心价值

现代分布式系统中API网关的关键作用：

功能维度	传统架构	网关架构
入口管理	多入口分散	统一入口管控
安全防护	各服务独立实现	集中式安全策略
流量控制	难以全局控制	精细化流量管理
监控分析	分散日志收集	统一监控大盘

二、核心架构设计

1. 系统分层架构

客户端 → API网关层 → 业务服务层 → 数据服务层
    ↑         ↑             ↑
鉴权/限流   请求转发      业务逻辑处理

2. 核心处理流程

请求接收 → 预处理 → 路由匹配 → 过滤器链 → 服务调用 → 响应处理
    ↑          ↑          ↑           ↑            ↑
SSL终止   参数校验    负载均衡    认证/限流/日志   数据聚合

三、关键技术实现

1. 高性能路由引擎

<?php
class Router
{
    private $routes = [];
    private $cacheFile;

    public function __construct(string $cacheFile = null)
    {
        $this->cacheFile = $cacheFile;
        $this->loadRoutes();
    }

    private function loadRoutes()
    {
        if ($this->cacheFile && file_exists($this->cacheFile)) {
            $this->routes = include $this->cacheFile;
            return;
        }

        // 从数据库或配置文件加载路由
        $routes = Db::table('gateway_routes')
            ->where('status', 1)
            ->select()
            ->toArray();

        foreach ($routes as $route) {
            $this->addRoute(
                $route['method'],
                $route['path'],
                $route['service'],
                $route['strip_prefix'] ?? false
            );
        }

        if ($this->cacheFile) {
            file_put_contents(
                $this->cacheFile,
                '<?php return ' . var_export($this->routes, true) . ';'
            );
        }
    }

    public function addRoute(string $method, string $path, string $service, bool $stripPrefix = false)
    {
        $method = strtoupper($method);
        $pattern = $this->compileRoute($path);

        $this->routes[$method][$pattern] = [
            'service' => $service,
            'params' => [],
            'strip_prefix' => $stripPrefix
        ];
    }

    private function compileRoute(string $path): string
    {
        // 转换 {param} 为正则捕获组
        $pattern = preg_replace('/{(w+)}/', '(?P[^/]+)', $path);
        return '#^' . $pattern . '$#';
    }

    public function match(string $method, string $uri): ?array
    {
        $method = strtoupper($method);
        if (!isset($this->routes[$method])) {
            return null;
        }

        foreach ($this->routes[$method] as $pattern => $config) {
            if (preg_match($pattern, $uri, $matches)) {
                $params = array_filter($matches, 'is_string', ARRAY_FILTER_USE_KEY);
                return [
                    'service' => $config['service'],
                    'params' => $params,
                    'strip_prefix' => $config['strip_prefix']
                ];
            }
        }

        return null;
    }
}

2. 过滤器链实现

<?php
interface Filter
{
    public function handle(Request $request, callable $next): Response;
}

class FilterChain
{
    private $filters = [];
    private $handler;

    public function addFilter(Filter $filter): self
    {
        $this->filters[] = $filter;
        return $this;
    }

    public function setHandler(callable $handler): self
    {
        $this->handler = $handler;
        return $this;
    }

    public function run(Request $request): Response
    {
        $runner = $this->handler;

        // 反向包装过滤器
        foreach (array_reverse($this->filters) as $filter) {
            $runner = function ($request) use ($filter, $runner) {
                return $filter->handle($request, $runner);
            };
        }

        return $runner($request);
    }
}

// 示例：认证过滤器
class AuthFilter implements Filter
{
    public function handle(Request $request, callable $next): Response
    {
        $token = $request->getHeader('Authorization');
        if (!$this->validateToken($token)) {
            return new Response(401, ['Content-Type' => 'application/json'], [
                'code' => 401,
                'message' => 'Unauthorized'
            ]);
        }

        return $next($request);
    }

    private function validateToken(string $token): bool
    {
        // JWT验证逻辑
        return true;
    }
}

四、高级功能实现

1. 智能限流系统

<?php
class RateLimiter
{
    private $redis;
    private $limits = [];

    public function __construct(Redis $redis)
    {
        $this->redis = $redis;
    }

    public function addLimit(string $key, int $limit, int $window): void
    {
        $this->limits[$key] = [
            'limit' => $limit,
            'window' => $window
        ];
    }

    public function check(string $key): bool
    {
        if (!isset($this->limits[$key])) {
            return true;
        }

        $limit = $this->limits[$key]['limit'];
        $window = $this->limits[$key]['window'];
        $now = time();

        // 滑动窗口算法
        $script = <<<LUA
local key = KEYS[1]
local now = tonumber(ARGV[1])
local window = tonumber(ARGV[2])
local limit = tonumber(ARGV[3])

local clearBefore = now - window
redis.call('ZREMRANGEBYSCORE', key, 0, clearBefore)

local currentCount = redis.call('ZCARD', key)
if currentCount >= limit then
    return 0
end

redis.call('ZADD', key, now, now)
redis.call('EXPIRE', key, window)
return 1
LUA;

        $result = $this->redis->eval(
            $script,
            [$key, $now, $window, $limit],
            1
        );

        return (bool)$result;
    }
}

// 使用示例
$limiter = new RateLimiter($redis);
$limiter->addLimit('api:user:123', 100, 60); // 用户每分钟100次

if (!$limiter->check('api:user:123')) {
    throw new RateLimitExceededException();
}

2. 服务熔断机制

<?php
class CircuitBreaker
{
    private $service;
    private $failureThreshold;
    private $recoveryTimeout;
    private $failures = 0;
    private $lastFailure = 0;
    private $state = 'closed';

    public function __construct(
        string $service,
        int $failureThreshold = 3,
        int $recoveryTimeout = 30
    ) {
        $this->service = $service;
        $this->failureThreshold = $failureThreshold;
        $this->recoveryTimeout = $recoveryTimeout;
    }

    public function execute(callable $operation)
    {
        if ($this->state === 'open') {
            if (time() - $this->lastFailure > $this->recoveryTimeout) {
                $this->state = 'half-open';
            } else {
                throw new ServiceUnavailableException();
            }
        }

        try {
            $result = $operation();
            $this->recordSuccess();
            return $result;
        } catch (Exception $e) {
            $this->recordFailure();
            throw $e;
        }
    }

    private function recordSuccess()
    {
        if ($this->state === 'half-open') {
            $this->state = 'closed';
            $this->failures = 0;
        }
    }

    private function recordFailure()
    {
        $this->failures++;
        $this->lastFailure = time();

        if ($this->failures >= $this->failureThreshold) {
            $this->state = 'open';
        }
    }

    public function getStatus(): array
    {
        return [
            'service' => $this->service,
            'state' => $this->state,
            'failures' => $this->failures,
            'last_failure' => $this->lastFailure
        ];
    }
}

五、性能优化策略

1. 连接池管理

<?php
class ConnectionPool
{
    private $pool;
    private $config;
    private $size;
    private $count = 0;

    public function __construct(array $config, int $size = 20)
    {
        $this->config = $config;
        $this->size = $size;
        $this->pool = new SplQueue();
    }

    public function getConnection()
    {
        if (!$this->pool->isEmpty()) {
            return $this->pool->dequeue();
        }

        if ($this->count < $this->size) {
            $this->count++;
            return $this->createConnection();
        }

        throw new RuntimeException('Connection pool exhausted');
    }

    public function releaseConnection($connection)
    {
        if ($connection->isConnected()) {
            $this->pool->enqueue($connection);
        } else {
            $this->count--;
        }
    }

    private function createConnection()
    {
        $conn = new SwooleCoroutineHttpClient(
            $this->config['host'],
            $this->config['port']
        );

        $conn->set([
            'timeout' => $this->config['timeout'] ?? 3.0,
            'keep_alive' => true
        ]);

        return $conn;
    }
}

2. 异步日志处理

<?php
class AsyncLogger
{
    private $queue;
    private $worker;

    public function __construct()
    {
        $this->queue = new SwooleCoroutineChannel(1000);
        $this->startWorker();
    }

    public function log(string $message, array $context = [])
    {
        $logEntry = [
            'time' => microtime(true),
            'message' => $message,
            'context' => $context
        ];

        $this->queue->push($logEntry);
    }

    private function startWorker()
    {
        go(function() {
            $file = fopen('gateway.log', 'a');

            while (true) {
                $logEntry = $this->queue->pop();

                $line = sprintf(
                    "[%s] %s %sn",
                    date('Y-m-d H:i:s', $logEntry['time']),
                    $logEntry['message'],
                    json_encode($logEntry['context'])
                );

                fwrite($file, $line);

                // 每100条刷新一次
                if ($this->queue->length() % 100 === 0) {
                    fflush($file);
                }
            }
        });
    }
}

六、实战案例：电商API网关

1. 商品服务路由配置

<?php
// 路由注册
$router->addRoute('GET', '/api/v1/products', 'product-service', true);
$router->addRoute('GET', '/api/v1/products/{id}', 'product-service', true);
$router->addRoute('POST', '/api/v1/products', 'product-service', true);

// 限流配置
$limiter->addLimit('api:products:list', 1000, 60); // 每分钟1000次
$limiter->addLimit('api:products:create', 100, 60); // 每分钟100次

// 过滤器配置
$chain = new FilterChain();
$chain->addFilter(new AuthFilter())
    ->addFilter(new RateLimitFilter($limiter))
    ->addFilter(new LoggingFilter($logger));

// 请求处理
$app->get('/api/v1/products', function(Request $request) use ($chain) {
    return $chain->setHandler(function($request) {
        $route = $router->match($request->getMethod(), $request->getPathInfo());
        $client = $pool->getConnection($route['service']);

        // 转发请求
        $response = $client->request($request);
        return new Response(
            $response->getStatusCode(),
            $response->getHeaders(),
            $response->getBody()
        );
    })->run($request);
});

2. 聚合API实现

<?php
public function getProductDetail(Request $request)
{
    $productId = $request->getAttribute('id');

    // 并行调用多个服务
    $results = Coroutinebatch([
        'product' => function() use ($productId) {
            return $this->callService('product-service', "/products/{$productId}");
        },
        'inventory' => function() use ($productId) {
            return $this->callService('inventory-service', "/stocks/{$productId}");
        },
        'reviews' => function() use ($productId) {
            return $this->callService('review-service', "/reviews?product_id={$productId}");
        }
    ]);

    // 数据聚合
    return [
        'id' => $productId,
        'title' => $results['product']['title'],
        'price' => $results['product']['price'],
        'stock' => $results['inventory']['quantity'],
        'rating' => $this->calculateRating($results['reviews']),
        'reviews' => array_slice($results['reviews'], 0, 5)
    ];
}

private function callService(string $service, string $path): array
{
    $client = $this->pool->getConnection($service);
    $response = $client->get($path);
    $this->pool->releaseConnection($client);

    if ($response->getStatusCode() !== 200) {
        throw new ServiceCallException("Service {$service} error");
    }

    return json_decode($response->getBody(), true);
}
